41 Menu operation
4. Main menu: Installation
Structure
Function descriptions
Menu Options
Projector Position Front/Front Ceiling/Rear/Rear Ceiling
3D Keystone
H: -40 – +40
V: -40 – +40
R: -40 – +40
Auto Vertical Keystone Off/On
12V Trigger Off/On
Test Pattern On/Off
High Altitude Mode On/Off
Serial Port Setting
Port Selection RS232/HDBaseT
Baud Rate
9600/14400/19200/38400/57600/
115200
Corner Fit 0~60
Image Resizing
Digital Zoom 1.0X – 1.8X/2.0X
Digital Shrink & Shift 0.75X~1.0X
Blanking
Modes of Adjustment
Top
Bottom
Left
Right
Warping
Enable On/Off
Warping Pattern 5x3/10x5/15x9/24x15
Warping Background
Warping Correction
Reset Reset/Cancel
Image Memory
Save Image Memory
Memory-1/Memory-2/Memory-3/
Memory-4/Memory-5
Apply Image Memory
Rename
Menu Descriptions
Projector
Position
The projector can be installed on a ceiling or behind a screen, or with one or
more mirrors. See Choosing a location on page 10 for details.
3D Keystone See Correcting keystone on page 16 for details.
Auto Vertical
Keystone
Automatically corrects the keystoning at the left/right side of the projected
image.
12V Trigger
There is one 12V trigger that works independently according to your needs
for installation scenarios.
• Off: If this is selected, the projector will not send electronic signal out
when it is turned on.
• On: The projector will send a low to high electronic signal out when it is
turned on, a high to low signal out when it is turned off.
