BenQ LX770 - Supported Timing for VIDEO;S-VIDEO Input; Supported Timing for HDMI;DVI-D (HDCP) Input

English
72
Supported timing for VIDEO/S-VIDEO input
Video mode
Horizontal
Frequency
(KHz)
Vertical Frequency
(Hz)
Sub-carrier
Frequency
(MHz)
3D Field
Sequential
NTSC 15.73 60 3.58
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
Supported timing for HDMI/DVI-D (HDCP) input
Resolution Mode
Refresh
Rate (Hz)
Horizontal
Frequency
(KHz)
Clock
(MHz)
3D Field
Sequential
3D Top-
Bottom
3D Side
by Side
640 x 480
VGA_60 59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
720 x 400 720 x 400_70 70.087 31.469 28.3221
800 x 600
SVGA_60 60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
SVGA_120
(Reduce Blanking)
119.854 77.425 83.000
1024 x 768
XGA_60 60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
XGA_120
(Reduce Blanking)
119.989 97.551 115.500
1152 x 864 1152 x 864_75 75.000 67.500 108.000
1024 x 576 BenQ NB Timing 60.000 35.820 46.996
1024 x 600 BenQ NB Timing 64.995 41.467 51.419
1280 x 720 1280 x 720_60 60.000 45.000 74.250
1280 x 768 1280 x 768_60 59.870 47.776 79.500
