7 Display installation guide
• Check the shock label on the outside of the product carton. The shock indicator on the label
will turn red if the display/package is improperly handled (for PL/PH series only).
Notes on installing the display
Installation of this display should only be performed by two (2) qualified technicians. Failure to
install this display properly may cause injuries and damages to the personnels and the display
itself.
• Be sure to use the alignment screw(s) to set the vertical alignment when installing the display.
• Leave some space in advance when installing the display. Use the alignment screw(s) on the
bracket to reduce the gap between the display to avoid collision.
• It is recommended to use the bracket which can be adjusted vertically and horizontally.
When you want to upturn the display, stand the display
vertically to make sure its weight spread evenly on the surface.
Alignment
screw
Wall
mount kit
To Next Page
