ITEM
Program
Menu
Equipments Requirement Procedure and SPEC
1. voltage confirming
Digital models Opposite white checks
screen
1697 1280*800/60Hz
1997 1440*900/60Hz
1. Using voltage model to measure output
place, checking whether voltage is right..
2. Connect Power, checking whether Power
LED present blue right
2. All reset and enter
into Burn in mode
1. In the meantime, press Keypad MENU
and VOL▼ Key to add AC POWER On to
purge EEPROM. When purged, it will
automatically enter into Factory mode.
2. Below VGA mode, no input signal will
automatically enter into Burn in mode.
After enter into Burn in mode, any
keyboard cannot rid Burn in, it must be
have VGA signal input before rid Burn in
mode.
3.VGA adjustment
(Factory mode)
PC or Pattern
Generator
5 Opposite white checks
screen
1697 1280*800/60Hz
1997 1440*900/60Hz
2297/2097
1680*1050/60Hz
6. Press” SOURCE” Key and select”
VGA”.
7. Check if each Timing can
display normally.
8. If there is a mode can not work
after shift, below 32 grey scale
picture. see if the color is flat.
9. Do not need color tempt change
self(besides OEM client)
1997/2097/2297:
WARM: x:313 y:329 Y:300±10%
COOL: x:283 y:297 Y:270±10%
1697:
WARM: x:313 y:329 Y:200±10%
COOL: x:283 y:297 Y:180±10%
10. without signal，it will enter
Burn-in mode.
