3.VGA adjustment
(Factory mode)
PC or Pattern Generator
5 Opposite white checks screen
1697 1280*800/60Hz
1997 1440*900/60Hz
2297/2097 1680*1050/60Hz
1. Press＂ SOURCE＂ Key and select＂
VGA＂.
2. Check if each Timing can display
normally.
3. If there is a mode can not work after
shift, below 32 grey scale pictures. See
if the color is flat.
4. Do not need color tempt change
self(besides OEM client)
1997/2097/2297:
WARM: x:313 y:329 Y:300±10%
COOL: x:283 y:297 Y:270±10%
1697:
WARM: x:313 y:329 Y:200±10%
COOL: x:283 y:297 Y:180±10%
5. without signal，it will enter Burn-in
mode.
3.1 VGA Setup
PC or Pattern
Generator
1. Press MENU Key to open OSD.
2. Press VOL▲▼Key to open VGA Setup.
3. After finished, choose MENU to exit.
a. Auto color
PC or Pattern
Generator
32 grey scale picture
1697 1280*800/60Hz
1997 1440*900/60Hz
2297/2097 1680*1050/60Hz
1. Press CH▲▼Key to choose Auto Color then
press VOL▲ Key to. enter
2. To confirm 32 scale picture Color is right.
3.2 Picture
PC or Pattern
Generator
Opposite white checks screen
1697 1280*800/60Hz
1997 1440*900/60Hz
2297/2097 1680*1050/60Hz
1. Press MENU Key to open OSD.
2. Press VOL▲▼ Key to select Picture.
3. Press CH▲▼ Key to adjust.
4. After that, choose MENU to exit.
a. Brightness
PC or Pattern
Generator
Opposite white checks screen
1697 1280*800/60Hz
1997 1440*900/60Hz
2297/2097 1680*1050/60Hz
1. Press CH▲▼ Key to choose Brightness.
2. Press VOL ▲ Key. Set upon clients
requirements.
