BV200 Plasma Viscometer Mk2/3 Customer User
Manual
Issue 9
th
Sep 2020 - Rev 1.8 Page 49 of 53
8. Barcode Reader Programming
The Viscometer contains a laser – it is only low level, used to read
barcodes.
Do not stare into the beam.
It is a class 2 laser product with a maximum output radiation of 1 mW.
The emitted wavelength is 630-680 nm to IEC 825-1 (1993)
8.1. Procedure
1. Switch on power to the Viscometer
2. Open the front cover of the Viscometer
3. Sweep the barcode strips through the red barcode beam from, „set‟ to „end‟.
4. As the barcode reader scans the „set‟ barcode, the sounder should give 3 audible
bleeps.”
5. When reading a code input the sound will change to a continuous 2 syllabul tone
(beep-bop).
6. As the barcode reader scans the „end‟ barcode, the sounder should give an additional
3 audible bleeps.”
7. If the sounder gives more than 3 bleeps, or continues to bleep, represent the end of
the strip to the reader until 3 audible bleeps are heard.
