USER MANUAL
TECHNICAL INFO
⚫ ** The below specification is based on the operating conditions at 18°C ~ 28°C with
relative humidity under 75%.
⚫ Accuracy: ([% of reading] + [number of least significant digits), guarantee for 1 year.
DC Voltage
Range
Resolution
Accuracy
200mV
0.1mV
±(0.8%rdg. + 5 digits)
2V
0.001V
±(0.5%rdg. + 5 digits)
20V
0.01V
±(0.5%rdg. + 5 digits)
200V
0.1V
±(0.5%rdg. + 5 digits)
1000V
1V
±(1%rdg. + 5 digits)
Input Impedance: 10MΩ
Overload protection: 1000V DC
AC Voltage
Range
Resolution
Accuracy
200mV
0.1mV
±(1.2%rdg. + 5 digits)
2V
0.001V
±(0.8%rdg. + 5 digits)
20V
0.01V
±(0.8%rdg. + 5 digits)
200V
0.1V
±(0.8%rdg. + 5 digits)
750V
1V
±(1.2%rdg. + 15 digits)
Input Impedance: 10MΩ
Overload protection: 750V AC
DC Current
Range
Resolution
Accuracy
2mA
0.001mA
±(0.8%rdg. + 5 digits)
20mA
0.01mA
±(0.8%rdg. + 5 digits)
200mA
0.1mA
±(1.2%rdg. + 5 digits)
20A
0.01A
±(2.0%rdg. + 10 digits)
Overload protection: 0.2A/250V fast acting fuse. 20A range is not fused. For 20A input
terminal, each measuring time should not more than 10 seconds within interval of 15
minutes.
