Model 865-A Deep Sea Acoustic Release/Transponder M-855-009
Benthos, Inc.
20
Board No. 1 (Driver Board) Top View
Figure 5-2
Transducer Connector
Board No. 2 (Logic Board) Top View
Figure 5-3
Interface Connector
Programming Cable Connector
