Bercomac Berco 700465 - Install Rotation Worm Assembly; Prepare and Install Handle

7
ASSEMBLY
Install rotation worm (item 2).
Item # Description Action
1 Flat washer 7/16’’, (2) Install on each
side of rotation
support.
2 Rotation worm Install in rotation
support.
3 2.5mm hair pin Secure rotation
worm shaft in
support.
Install rotation worm
Prepare handle
Prepare handle (item 3).
Item # Description Action
1 Hand grip Install on
handle.
2 Hair pin Install on
handle.
