16
CC
CC
C
.A.A
.A.A
.A
.I.I
.I.I
.I
.:.:
.:.:
.:
pr pr
pr pr
pr
ogog
ogog
og
rr
rr
r
aa
aa
a
mmabmmab
mmabmmab
mmab
le parle par
le parle par
le par
aa
aa
a
metersmeters
metersmeters
meters
N° DESCRIPTION PARAMETERS UNIT OF MIN MAX DEFAULT PARAMETERS
PAR. MEASURE (setted in factory) (setted by techn. assist. centre)
1 GAS TYPE 1 Methane 1-2
2 LPG
3 Methane France
3 INSULATION LEVEL OF BUILDING (+) (*) min 5 20 5
10 DHW MODE 0 (OFF) 1
1 (Instantaneous)
2 (Mini-tank)
3 (External water-tank with thermostat)
4 (External water-tank with sensor)
11 DHW CIRCUIT MAXIMUM SET-POINT ° C 40 60 60
12 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 60
13 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 80
14 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 5
20 CH MODE 0 (OFF) 1
1 (ON)
2 (zone valves + remote control panel)
21 HEATING CIRCUIT MAXIMUM SET-POINT ° C 40 80 80
22 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 40
28 MAX HEATING POWER REDUCTION TIMER min 0 20 15
29 FORCED HEATING SHUT DOWN TIMER min 0 20 3
30 HEATING TIMER RESET FUNCTION - 0 1 0
40 DHW THERMOSTAT OPERATING MODE 0 (OFF) 1
1 (AUTO)
2 (ON)
41 DHW PREHEATING FUNCTION 0 (OFF) 1
1 (AUTO)
2 (ON)
42 S.A.R.A. FUNCTION 0 (OFF) 1
1 (AUTO)
43 S.A.R.A. BOOSTER FUNCTION 0 (OFF) 1
1 (AUTO)
44 THERMOREGULATION FUNCTION 0 (OFF) 1
1 (AUTO)
45 INCLINATION THERMOREGULATION CURVE (OTC) (*) - 2,5 40 20
48 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 0
50 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
61 DHW ANTIFREEZE FUNCTION TEMPERATURE (ON) °C 0 10 4
62 HEATING ANTIFREEZE FUNC. DELIVERY TEMP. (ON) °C 0 10 6
85 SEMI-AUTOMATIC FILLING 0 (disabled)/1 (enabled) 1
86 AUTOMATIC FILLING PRESSURE (ON) bar 0.4 0.8 0.6
MIX CMIX C
MIX CMIX C
MIX C
.S.S
.S.S
.S
.I.I
.I.I
.I
.:.:
.:.:
.:
pr pr
pr pr
pr
ogog
ogog
og
rr
rr
r
aa
aa
a
mmabmmab
mmabmmab
mmab
le parle par
le parle par
le par
aa
aa
a
metersmeters
metersmeters
meters
N° DESCRIPTION PARAMETERS UNIT OF MIN MAX DEFAULT PARAMETERS
PAR. MEASURE (setted in factory) (setted by techn. assist. centre)
1 GAS TYPE 1 Methane 1-2
2 LPG
3 Methane France
2 BOILER POWER 26 (26kW) 26-30-34
30 (30kW)
34 (35kW)
3 INSULATION LEVEL OF BUILDING (+) (*) min 5 20 5
10 DHW MODE 0 (OFF) 1
1 (Instantaneous)
2 (Mini-tank)
3 (External water-tank with thermostat)
4 (External water-tank with sensor)
11 DHW CIRCUIT MAXIMUM SET-POINT ° C 40 60 60
12 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 60
13 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 80
14 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 5
20 CH MODE 0 (OFF) 1
1 (ON)
2 (zone valves + remote control panel)
21 HEATING CIRCUIT MAXIMUM SET-POINT ° C 40 80 80
22 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 40
28 MAX HEATING POWER REDUCTION TIMER min 0 20 15
29 FORCED HEATING SHUT DOWN TIMER min 0 20 3
30 HEATING TIMER RESET FUNCTION - 0 1 0
40 DHW THERMOSTAT OPERATING MODE 0 (OFF) 1
1 (AUTO)
2 (ON)
41 DHW PREHEATING FUNCTION 0 (OFF) 1
1 (AUTO)
2 (ON)
42 S.A.R.A. FUNCTION 0 (OFF) 1
1 (AUTO)
43 S.A.R.A. BOOSTER FUNCTION 0 (OFF) 1
1 (AUTO)
44 THERMOREGULATION FUNCTION 0 (OFF) 1
1 (AUTO)
45 INCLINATION THERMOREGULATION CURVE (OTC) (*) - 2,5 40 20
48 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 0
50 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
61 DHW ANTIFREEZE FUNCTION TEMPERATURE (ON) °C 0 10 4
62 HEATING ANTIFREEZE FUNC. DELIVERY TEMP. (ON) °C 0 10 6
85 SEMI-AUTOMATIC FILLING 0 (disabled)/1 (enabled) 1
86 AUTOMATIC FILLING PRESSURE (ON) bar 0.4 0.8 0.6
(*) parameters shown only with external sensor connected and parameter 44 in 1 (AUTO).
(+) for well-insulated buildings select values close to 20, for badly insulated buildings choose values close to 5.
T m. = maximum rated temperature of heating water
T e. = minimum rated external temperature
OTC = 10 x
Tm. - 20
20 - Te.
Parameter 45 “Inclination of thermoregulation curve (OTC)”
The curve must be chosen according to the geographical area and the type
of installation.
