N° DESCRIPTION PARAMETERS UNIT OF MIN MAX DEFAULT PARAMETERS
PAR. MEASURE (setted in factory) (setted by techn. assist. centre)
1 GAS TYPE 1 Methane 1-2
2 LPG
3 Methane France
3 INSULATION LEVEL OF BUILDING (+) (*) min 5 20 5
10 DHW MODE 0 (OFF) 3
1 (Instantaneous)
2 (Mini-tank)
3 (Ext. water-tank with thermostat - A & B cases)
4 (Ext. water-tank with sensor - C case)
11 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 60
12 WATER TANK MAXIMUM SET-POINT °C 40 80 60
13 DELIVERY TERMPERATURE EXT. WATER TANK °C 50 80 80
14 DELTA EXTERNAL WATER TANK (ON) °C 0 10 5
20 CH MODE 0 (OFF) 1
1 (ON)
2 (zone valves + remote control panel)
21 HEATING CIRCUIT MAXIMUM SET-POINT ° C 45 80 80
22 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 40
28 MAX HEATING POWER REDUCTION TIMER min 0 20 15
29 FORCED HEATING SHUT DOWN TIMER min 0 20 3
30 HEATING TIMER RESET FUNCTION - 0 1 0
40 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
41 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
42 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
43 S.A.R.A. BOOSTER FUNCTION 0 (OFF) 1
1 (AUTO)
44 THERMOREGULATION FUNCTION 0 (OFF) 1
1 (AUTO)
45 INCLINATION THERMOREGULATION CURVE (OTC) (*) - 2,5 40 20
48 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 0
50 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
61 DHW ANTIFREEZE FUNCTION TEMPERATURE (ON) °C 0 10 4
62 HEATING ANTIFREEZE FUNC. DELIVERY TEMP. (ON) °C 0 10 6
85 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
86 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 0.6
MIX R.SMIX R.S
MIX R.SMIX R.S
MIX R.S
.I.I
.I.I
.I
.:.:
.:.:
.:
pr pr
pr pr
pr
ogog
ogog
og
rr
rr
r
aa
aa
a
mmabmmab
mmabmmab
mmab
le parle par
le parle par
le par
aa
aa
a
metersmeters
metersmeters
meters
N° DESCRIPTION PARAMETERS UNIT OF MIN MAX DEFAULT PARAMETERS
PAR. MEASURE (setted in factory) (setted by techn. assist. centre)
1 GAS TYPE 1 Methane 1-2
2 LPG
3 Methane France
2 BOILER POWER 26 (26kW) 30
30 (30kW)
34 (35kW)
3 INSULATION LEVEL OF BUILDING (+) (*) min 5 20 5
10 DHW MODE 0 (OFF) 3
1 (Instantaneous)
2 (Mini-tank)
3 (Ext. water-tank with thermostat - A & B cases)
4 (Ext. water-tank with sensor - C case)
11 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 60
12 WATER TANK MAXIMUM SET-POINT °C 40 80 60
13 DELIVERY TERMPERATURE EXT. WATER TANK °C 50 80 80
14 DELTA EXTERNAL WATER TANK (ON) °C 0 10 5
20 CH MODE 0 (OFF) 1
1 (ON)
2 (zone valves + remote control panel)
21 HEATING CIRCUIT MAXIMUM SET-POINT ° C 45 80 80
22 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 40
28 MAX HEATING POWER REDUCTION TIMER min 0 20 15
29 FORCED HEATING SHUT DOWN TIMER min 0 20 3
30 HEATING TIMER RESET FUNCTION - 0 1 0
40 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
41 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
42 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
43 S.A.R.A. BOOSTER FUNCTION 0 (OFF) 1
1 (AUTO)
44 THERMOREGULATION FUNCTION 0 (OFF) 1
1 (AUTO)
45 INCLINATION THERMOREGULATION CURVE (OTC) (*) - 2,5 40 20
48 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 0
50 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
61 DHW ANTIFREEZE FUNCTION TEMPERATURE (ON) °C 0 10 4
62 HEATING ANTIFREEZE FUNC. DELIVERY TEMP. (ON) °C 0 10 6
85 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 1
86 THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY 0.6
(*) parameters shown only with external sensor connected and parameter 44 in 1 (AUTO).
(+) for well-insulated buildings select values close to 20, for badly insulated buildings choose values close to 5.
T m. = maximum rated temperature of heating water
T e. = minimum rated external temperature
OTC = 10 x
Tm. - 20
20 - Te.
Parameter 45 “Inclination of thermoregulation curve (OTC)”
The curve must be chosen according to the geographical area and the type
of installation.
