7
ENGLISH
3.12 Flue gas discharge and air suction
Observe local legislation regarding ue gas discharge.
Flue gases are discharged from a centrifugal fan located inside the combustion
chamber and the control board constantly checks that this is working correctly.
The boiler is supplied without the ue gas discharge/air suction kit, since it is
possible to use the accessories for appliance with a forced draught sealed
chamber that better adapts to the installation characteristics. For ue gas
extraction and the restoration of boiler combustion air, it is essential to only
use certied piping. Connection must be carried out correctly as indicated in
the instructions supplied as standard with the ue gas accessories.
Multiple appliances can be connected to a single smoke pipe provided that
each is a sealed chamber-type appliance. The boiler is a Type C appliance
(sealed chamber), and must therefore have a safe connection to the ue
gas discharge pipe and to the combustion air suction pipe; these both carry
their contents outside, and are essential for the operation of the appliance.
b
The maximum lengths of the ducts refer to ue systems available in
the catalogue.
b
The straight length measurement is inclusive of the rst bend (boiler
connection), terminals and joints; with the exception of the vertical
coaxial duct Ø 60-100 mm, where the straight length does not include
the bends.
POSSIBLE OUTLET CONFIGURATIONS (g. 23)
B23P/B53P Suction indoors and discharge outdoors
C13-C13x Discharge via concentric wall outlet. The pipes may leave the
boiler independently, but the outlets must be concentric or sufciently close
together to be subjected to similar wind conditions (within 50 cm)
C33-C33x Discharge via concentric roof outlet. Outlets as for C13
C43-C43x Discharge and suction in common separate smoke pipes, but
subjected to similar wind conditions
C53-C53x Separate discharge and suction lines on wall or roof and in areas
with different pressures. The discharge and suction lines must never be
positioned on opposite walls
C63-C63x Discharge and suction lines using pipes marketed and certied
separately (1856/1)
C83-C83x Discharge via single or common smoke pipe and wall suction line
C93-C93x Discharge on roof (similar to C33) and air suction from a single
existing smoke pipe
“FORCED OPEN” INSTALLATION (TYPE B23P/B53P)
Flue gas discharge pipe ø 80 mm (g. 20)
The ue gas discharge pipe can be directed to the most suitable direction
according to installation requirements. For installation, follow the instructions
supplied with the kit. In this conguration, the boiler is connected to the ue
gas discharge pipe (ø 80 mm) through an adaptor (ø 60-80 mm).
b
In this case, the combustion air is picked up from the boiler installation
room (which must be a suitable technical room with proper ventilation).
b
Uninsulated ue discharge outlet pipes are potential sources of
danger.
b
Arrange the ue gas discharge pipe so it slopes by 3° towards the boiler.
b
The boiler automatically adapts the purging to the type of installation
and the length of the pipe.
maximum length of the ue gas
discharge pipe ø 80 mm
pressure drop
45° bend 90° bend
25 C.S.I. 70 m
1 m 1,5 m
29 C.S.I. 65 m
“SEALED” INSTALLATION (TYPE C)
The boiler must be connected to concentric or twin ue gas discharge
pipes and air suction pipes, both leading outdoors. The boiler must not be
operated without them.
Concentric pipes (ø 60-100 mm) (g.21)
The concentric pipes can be placed in the most suitable direction according
to installation requirements, complying with the maximum lengths indicated
in the table.
b
Arrange the ue gas discharge pipe so it slopes by 3° towards the
boiler.
b
Non-insulated outlet pipes are potential sources of danger.
b
The boiler automatically adapts the purging to the type of installation
and the length of the pipe.
b
Do not obstruct or choke the combustion air suction pipe in any way.
For installation, follow the instructions supplied with the kit.
straight length
concentric pipe ø 60-100 mm
pressure drop
45° bend 90° bend
Horizontal Vertical
25 C.S.I. 5,85 m 6,85 m
1,3 m 1,6 m
29 C.S.I. 4,85 m 5,85 m
Concentric pipes (ø 80-125 mm)
For this conguration, the special adaptor kit must be tted. The concentric
pipes can face in the direction most suitable for installation requirements.
For installation, follow the instructions supplied with the specic condensing
boilers kits.
straight length
concentric pipe ø 80-125 mm
pressure drop
45° bend 90° bend
25 C.S.I. 15,3 m
1,0 m 1,5 m
29 C.S.I. 12,8 m
Twin pipes (ø 80 mm) (g. 22)
The twin pipes can face in the direction most suited to the installation
requirements. For installation, follow the instructions supplied with the
specic accessory kit for condensing boilers.
To use the combustion air suction pipe, one of the two inlets (A and B) must
be selected. Remove the closure plug which is xed using screws, and use
the specic adaptor relating to the inlet selected (C air inlet adaptor ø 80 - D
air inlet adaptor from ø 60 to ø 80) available as an accessory.
b
Arrange the ue gas discharge pipe so it slopes by 3° towards the
boiler.
b
The boiler automatically adapts the purging to the type of installation
and the length of the pipes. Do not obstruct or choke the pipes in any
way.
b
Refer to the graphs to nd the maximum lengths of the single pipe.
b
The use of longer pipes reduces the boiler output.
maximum straight length
twin pipes ø 80 mm
pressure drop
45° bend 90° bend
25 C.S.I. 45 + 45 m
1,0 m 1,5 m
29 C.S.I. 40 + 40 m
Suction pipe length (m)
Discharge pipe length (m)
80
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95
100
105
110
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95
MAXIMUM STRAIGHT LENGTH Ø 80
Ciao Green 25 C.S.I.
Ciao Green 29 C.S.I.
Discharge pipe length (m)
Suction pipe length (m)
