Boiler faults list
ERROR
CODE
FAULT
RED
LED
GREEN
LED
RED & GREEN
LED
DESCRIPTION OF ALARM
TYPE
E010 ame lockout/ACF electronic fault ON denitive
E011 extraneous ame
ashing 0,2 sec. ON/
0,2 sec. OFF
transitional
E020 limit thermostat
ashing 0,5 sec. ON/
0,5 sec. OFF
denitive
E030 fan fault ON denitive
E040 water transducer – load system ON denitive
E041 water transducer – load system
ashing 0,5 sec. ON/
0,5 sec. OFF
transitional
E042 water pressure transducer fault ON denitive
E060 domestic hot water probe fault
ashing 0,5 sec. ON/
0,5 sec. OFF
transitional
E070
ow sensor fault
ow sensor overtemperature
ow/return sensor differential alarm
ON
transitional
denitive
denitive
E077 water thermostat main zone or zone 1 (when enabled) ON transitional
E080
return line probe fault
return line probe overtemperature
outlet/return line probe differential alarm
ON
transitional
denitive
denitive
E084 delivery line probe fault - zone 1
ashing 0,5 sec. ON/
3 sec. OFF
transitional
E086 delivery line probe fault - main zone
ashing 0,5 sec. ON/
3 sec. OFF
transitional
E090
ue gas probe fault
ue gas probe overtemperature
ashing 0,5 sec. ON/
0,5 sec. OFF
transitional
denitive
E091 clean primary heat exchanger
ashing 0,5 sec. ON/
0,5 sec. OFF
transitional
E099 reset attempts exhausted, boiler blocked It is referred to the last fault occurred denitive, not resettable
<0,6 bar low pressure - check the system
ashing 0,5 sec. ON/
0,5 sec. OFF
signalisation
>3,0 bar high pressure - check the system
ashing 0,5 sec. ON/
0,5 sec. OFF
signalisation
COM lost communication with boiler board ON transitional
COMP lost communication with main zone
ashing 0,5 sec. ON/
3 sec. OFF
transitional
COM1 lost communication with zone 1
ashing 0,5 sec. ON/
3 sec. OFF
transitional
FWER FW version not compatible
ashing 0,5 sec. ON/
3 sec. OFF
denitive
OBCD damaged clock
ashing 0,5 sec. ON/
0,5 sec. OFF
signalisation
OTER OTBus conguration fault
ashing 0,5 sec. ON/
3 sec. OFF
List of combustion faults
ERROR
CODE
RED LED GREEN LED FAULT DESCRIPTION OF ALARM TYPE
E021 ON ion alarm
These are temporary alarms that if they occur 6 times in an hour they become denitive; the E097 alarm is displayed and
is followed by post-purging for 45 seconds at the fan's maximum speed.
It is not possible to release the alarm before the end of the post-purging unless the boiler's power supply is switched off.
E022 ON ion alarm
E023 ON ion alarm
E024 ON ion alarm
E067 ON ion alarm
E088 ON ion alarm
E097 ON ion alarm
E085 ON incomplete combustion
These are temporary alarms that if they occur several times in an hour they become denitive; the last error to occur is
displayed and is followed by a post-purging of 5 minutes at the fan's maximum speed.
It is not possible to release the alarm before the end of the post-purging unless the boiler's power supply is switched off.
E094 ON incomplete combustion
E095 ON incomplete combustion
E058 ON mains voltage fault
These are temporary faults that restrict the ignition cycle.
E065 ON current modulation alarm
E086 ON ue gases obstruction alarm Temporary fault signalled during pre-purging. Post-purging is maintained for 5 min at maximum fan speed.
Warning lights
BOILER STATUS RED LED GREEN LED RED and GREEN NOTES
Power-on ashing 0.5 sec. on/0.5 sec. off The red and green LEDs come on at the same time
Vent cycle ashing 0.5 sec. on/1 sec. off ashing 0.5 sec. on/1 sec. off The red and green LEDs come sequentially one at a time
OFF status ashing 0.3 sec. on/0.5 sec. off
No heat request (stby) ashing 0.3 sec. on/0.5 sec. off
Transitional ignition/
overtemperature
ashing 0.3 sec. on/0.5 sec. off
Presence of ame ON
Chimney sweep ON Only if the ame is present
Screed heating ashing 1 sec. on/1 sec. off ashing 1 sec. on/1 sec. off The red and green LEDs come on alternately
