Service and Installation Manual
INSTALLATION
Location
Units represented in this manual are intended for indoor use only. Be sure the location chosen has a floor
strong enough to support the total weight of the cabinet and contents. A fully loaded unit can weigh as much
as 1500 pounds. Reinforce the floor as necessary to provide for maximum loading. For the most efficient
refrigeration, be sure to provide good air circulation inside and out.
NOTE: The cabinet is fixed on the wooden pallet with screws, remove the screws before
moving the cabinet from the pallet.
Door handle is packed and fixed on the shelf inside the cabinet, after locating the cabinet, take out the door
handle, and install it with cross screwdriver according to following instruction:
Inside cabinet:
Do not pack the units so full that air cannot circulate. The refrigerated air is discharged at the top rear of
the unit. It is important to allow for proper air flow from the top rear to the bottom of the unit. Obstructions to
this air flow can cause evaporator coil freeze ups and loss of temperature or overflow of water from the
evaporator drain pan. The shelves have a rear turn up on them to prevent this. However, bags and other
items can still be located to the far rear of the cabinet. Air is brought into the evaporator coil with fans mounted
to the front of the coil.
