Berkley Tool SSHM-2 - User Manual

Questions and Answers

Y
yfloydAug 2, 2025
What to do if my Berkley Tool SSHM-2 Water Pump motor will not run?
- E
  erinjensenAug 2, 2025
  If your Berkley Tool Water Pump motor isn't running, here are a few things to check: * Ensure the disconnect switch is turned on. * Inspect the fuse and replace it if it's blown, or reset the circuit breaker if it has tripped. * Check the wiring at the motor to make sure the wires are tightened and connected correctly after disconnecting the power. If the starting switch is defective, disconnect the power and replace it.
J
Juan JordanAug 21, 2025
How to fix a Berkley Tool SSHM-2 Water Pump motor that runs hot and the overload kicks off?
- K
  Kevin MooreAug 21, 2025
  If your Berkley Tool Water Pump motor runs hot and the overload protection activates, it could be due to incorrect wiring. Refer to the wiring instructions. Another possibility is low voltage. Check with your power company or install heavier wiring if the wire size is too small; refer to the Electrical / Wiring Chart.
D
Donald PetersonNov 10, 2025
Why is my Berkley Tool SSHM-2 motor running, but no water is being delivered?
- S
  Sonya WilliamsNov 10, 2025
  If your Berkley Tool Water Pump motor runs but no water comes out, consider these possibilities: * If it's a new installation, the pump might not have picked up prime. Re-prime it according to the instructions. * There could be air leaks in the suction line. Check all connections with soapy water or shaving cream. * The foot valve or check valve might be leaking or stuck. Consider replacing them. * The pump may have lost prime, so inspect all connections on the suction line and shaft seal. * The water level might be below the suction pipe inlet; lower the suction line and re-prime. * The foot valve or strainer could be plugged; clean them. * The impeller might be plugged; clean it. * The pipes could be frozen; thaw them. * The foot valve and/or strainer might be buried i...

Summary

Safety

Understanding Safety Instructions

Guidelines for understanding safety alert symbols and label notices for injury prevention.

General Safety Precautions

General safety precautions and operating limits for pump use, including pressure, temperature, and starting frequency.

Installation

Pre-Installation Checks

Pre-installation checks and warnings, including water depth, pipe conditions, freezing protection, and booster pump use.

Well Installation Types

Instructions for installing pumps in cased, dug, or driven point wells, including pipe connections and foot valve placement.

Piping and Discharge Considerations

Guidelines for horizontal suction pipe runs and increasing discharge pipe sizes to reduce friction loss.

Sprinkling Application Guidelines

Advice on using the pump for sprinkling systems and managing multiple discharge points.

Pump Mounting and Piping Support

Steps for securing the pump, supporting piping, sealing joints, and ensuring air-tight suction lines.

Electrical Wiring Procedures

Essential safety precautions and procedures for connecting the pump motor to the electrical supply.

Electrical

Motor Wiring Diagrams

Visual guides for connecting single-phase and three-phase motors to the power supply.

Wire and Fuse Size Chart

Table specifying recommended wire gauges and fuse sizes based on motor HP and distance from supply.

Operation

Priming the Pump

Detailed steps for filling the pump and suction piping with water to ensure proper operation and prevent damage.

Maintenance

Routine Maintenance and Draining

General maintenance tips, including shaft seal care and draining the pump for service or freeze protection.

Pump Disassembly Steps

Step-by-step instructions for taking the pump apart, including removing the suction body, impellers, and motor.

Shaft Seal Service

Detailed steps for removing and installing the mechanical shaft seal, including cleaning and seating procedures.

Pump Reassembly Procedure

Instructions for reassembling the pump after maintenance, including seal installation, impeller mounting, and tightening procedures.

Troubleshooting

Common Pump Problems and Solutions

A guide to diagnosing and resolving common pump issues like motor not running, overheating, or no water delivery.

Repair Parts

Exploded View and Parts List

Diagram of pump components and a list of part numbers for ordering replacements.
