6
Outlet
Seal ring
Axle sleeve
Shaft
Pump
Body
Impeller
Rotor cover
Front cover
Specifications
MODEL BER CODE OUTPUT POWER HMAX HOSETAILS DIMENSIONS
400 BER0001 350lph / 77gph 6W 0.8m 13mm 69 x 54 x 82mm
750 BER0057 750lph / 165gph 12W 1.5m 13mm 75 x 57 x 92mm
1000 BER0058 1,000lph / 220gph 16W 1.8m 16mm 89 x 70 x 111mm
1500 BER0059 1,500lph / 330gph 25W 2.5m 19mm 104 x 93 x 140mm
2000 BER0392 2,000lph / 440gph 43W 3.0m 19mm 118 x 101 x 158mm
3000 BER0083 3,000lph / 660gph 68W 3.5m 25mm 132 x 106 x 172mm
4000 BER0084 4,000lph / 880gph 75W 3.0m 25mm 132 x 106 x 172mm
Exploded view
Feature Pumps - Instruction Manual - FP Pumps 2021.indd 6 28/09/2020 14:32:21
