32
When inserting or removing the
bobbin, the needle must be fully raised.
· Open the hinged cover (1).
· Remove the bobbin case by pulling its
latch towards you and pulling it out
from the hook.
· Hold the bobbin case with one hand.
Insert the bobbin so that the thread
runs in a clockwise direction (arrow)
(2).
· Pull the thread through the slit and
under the finger (3). spring
· Hold the bobbin case by the hinged
latch (4).
· Insert it into the hook (5). Make sure
the bobbin case finger fits into the
notch (6) at the top of the race.
Attention:
Turn power switch to off (“O”) before
inserting or removing the bobbin.
Inserting bobbinEN
34
When inserting or removing the
bobbin, the needle must be fully raised.
· To open the bobbin cover, slide it against
you.
· Inserting the bobbin in the bobbin holder
with the thread running counter
clockwise direction. (1)
· Pull the thread through the slit. (2)
· Guide the thread end around the finger
through the slot, first to the left then to
the front. (3) Then pull the thread to the
back left to cut off excess thread.(4)
· Close bobbin cover, by pushing it to the
back.
There is no need to pull up the lower
thread, if excess thread is cut off.
Attention:
Turn power switch to “O” before inserting
or removing the bobbin.
Inserting bobbin
EN
