5Details
1 Bobbin cover
2 Stitch plate
3 Attachment base for
special accessories
4 Sewing table socket
5 Presser foot
6 Needle clamp with
fixation screw
7 Thread guide
8 Thread take up cover
9 Thread path
10 Thread tension
adjustment
11 Bobbin pre-tension
12 Reverse button/quick and
continuous
13 Screen
14 Bobbin winder with
on/off switch and thread
cutter
15 Stitch width button
16 Needle position button
17 Stitch length button
18 Needle stop up/down
19 1/2 speed
20 Stitch selection buttons
21 #-button
22 clr/del-button
23 Handwheel
24 FHS connection
25 Balance adjustment knob
26 Power switch on/off
27 Power plug socket
28 Drop feed-dog
29 Foot control socket
30 Spool pin (vertical,
collapsible)
31 Start-stop-unit (optional)
23
10
14
11
30
26
27
25
29
28
Right end
