BERNSTEIN WC T620 Pro - Installation Instructions 2

23
Level ground
INSTALLATION INSTRUCTIONS 2
2. Place the Toilet mat on your nished wall in the designated position as shown. Align the mat with the ush opening,
the waste water connection and the prepared mounting threaded rods of the shower toilet and rst run the water
outlet pipe in front of the installation.
SPARE PARTS LIST
Remote control assembly Hexagon wrench Fixing pins
2 x
Expansion
screw set
2 x
Ball valve Double ended
Water inlet pipe
Instruction
manual
Toilet mat Screw
2 x
Covers
2 x
Gaskets
2 x
Installation hole
Water outlet pipe hole
Water outlet pipe
SHOWER-WC T620 Pro
