INSTALLATION INSTRUCTIONS 4
4. After the toilet is near the wall, use a spirit level to set up the product and keep it in a horizontal position.
Place the plastic plugs and a stainless steel seal on the xed screw one after the other and then tighten the nut.
Then connect the ball valve to the head of the outlet pipe and pass water through to remove any foreign matter.
Insert the xing pins into the xing holes.
Fixing screw
Plastic plug
Stainless steel pad
Lock nut
Toilet xing hole
Fixing pins
Open the ball valve
to drain the water
5. Connect the head part as shown in the illustration.
INSTALLATION INSTRUCTIONS 5
Leakage protected power cable
Knob wire
Ball valve
Water outlet pipe
SHOWER-WC T620 Pro
