GAS CONVERSION
STEP 3: OVEN BURNER (MAIN OR
AUXILIARY)
To replace the nozzles of the main oven burner, start by
removing the door and the bottom panel of the oven.
Fig. 25
Remove the screw located on the right side of the burner
and pull out the burner from its support.
CAUTION
ATTENTION: pay extra attention to avoid
damage to the igniter and thermocouple.
Fig. 26
Unscrew the nozzle located inside the gas fitting using a 7
mm [socket wrench].
Replace the nozzle as table number 1.
Fig. 27
27
