18
6.1 Internal Layout (positioning, adjust-
ment, removal).
Crisper
Fixed to the slide guides with two thumbscrews.
> to remove the drawer, unscrew the thumbscrews
and remove the drawer.
Warning
Do not place hands or fingers near the Ice-
maker when in function.
Shelves
The shelves are moveable and can be easily re-posi-
tioned by the user as follows:
> release the locking knob by turning counter-clock-
wise
> lift or lower the shelf to the desired position
> re-tighten the locking knob. To remove a shelf it is
necessary to slide it up to the top
6. INTERNAL LAYOUT
Door Bins
The door bins can be easily removed for cleaning
> Hold the door shelf at the sides and push it upwards
to release it from its seat, then pull it outwards.
> Reverse the procedure to reinstall.
