SCHEMAS_ELECTRIQUES_GC 16
R
Schéma de câblage NIVELEC
NIVELEC wiring diagram
522.685 C
RACER PORTES
MACK
Tractés
B
A4m
10m
4m
10m
4m
5m
BP 5
BP 4
J5
321
J3
321
J4
321
BATTERIE
+
-
Contact
Boîtier jauge
VUE ARRIERE
Câble d'alimentation
2 x 0,5²
Blanc
Marron
Blanc Marron
A
B
Câble blindé
3 x 0,34²
Bleu ou vert
Blanc
Rouge ou marron
Blindage
Voir câblage
du
potentiomètre
