CONTROL PANEL PARTS LIST
Drawings and Parts Lists
BMCPMSD5A
KEY NO. PART NO. QTY DESCRIPTION
1 C4801001 1 BOX, ELECTRICAL SHELL
2 C4802002 1 BOX, ELECTRICAL DRAWER
3 2811190 1 RELAY, THERMAL 4.0-6.0AMPS
4 2810117 1 RELAY, MAGNETIC SC-03-4A 110V
5 2896307-4 2 CAPACITOR, 18UF 250VAC
6 2861020 3 CONNECTOR, STRAIGHT(MG-16A-10B
7 2870185 1 SWITCH, ON/OFF RENY R2PID-W-1
8 2843801 1 TERMINAL, BLOCK PA10F-12
9 2890020 1 HOLDER, FUSE TFB101
10 2882401 1 CORD, ELECTL W/ PLUG 1.25 3M
11 2890043 1 FUSE, GLASS 10AMP 30mm
12 2705006 2 WASHER, FLAT M4
13 2705103 2 WASHER, FLAT M5
14 2705102 3 WASHER, FLAT M6
15 2703203 1 SCREW, OVAL HD PHILIP M4X8
16 2703225 1 SCREW, OVAL HD PHILIP M4X10
17 2703206 2 SCREW, OVAL HD PHILIP M4X12
18 2703200 2 SCREW, OVAL HD PHILIP M4X15
19 2703207 2 SCREW, OVAL HD PHILIP M5X6
20 2701501 2 SCREW, OVAL HD M6X12
21 2700026 1 SCREW, HEX HD M6X12
22 2707102 3 NUT, HEX JAM NYLOCK M6
To Next Page
