Wiring and Precautions
➢ Connect one end of the cable to the terminal box of the machine, and connect the other
end to the socket.
➢ Connect the power supply according to the voltage on the label, or the machine might be
damaged.
➢ Please confirm whether there is grounding in the socket to avoid unnecessary damage.
➢ If the grounding cannot be done through the socket, please try other methods.
Socket
Terminal box
Plug
Cable
Plug
Warning: The working voltage of the machine is 220V. Please connect
the power supply according to the label, or the machine might be damaged.
