BETTERI BC01 - Main Technical Features

BC01
Instruction Book Of BC01 cable to cable
5
4. Main Technical Features
Item Parameter Item Parameter
Applicable
environment
temperature
-40℃～+85℃
Over-voltage
category
III
Relative humidity
≤95%
Wirin
g
Connection
Screw type
electrode
number
2P+PE
Insulation resistance
≥100MΩ
Rated voltage
TUV: 250V AC
CSA: 350V AC
Rated impulse
withstand voltage
4000V AC
Rated current
25A(4mm²)
Degree of
protection
IP68（1.5m,24h）
Material of pin
Copper alloy &silver
plated
Insertion and
withdraw
force(unlocked)
10～50N
Contact resistance
≤1mΩ
Applicable wire
gauge
2.5/4.0mm
2
Pollution degree
2
Outer cable
diameter
10～13mm
Enclosure flame
class
UL94-V0
Standards
UL6703A
EN 61535
PPP 59015A:2013
