4. DEVICE DESCRIPTION
Overview of the control unit
No. Designation
1 On/O/Pause button
2 Intensity setting
▲ Increase
▼ Lower
3 Program/lock button
4 Battery compartment
5 Connector socket
6 Screen with LCD display
7 Battery status, appears when batteries are dead
8 Intensity, level 0 – 20
9 Pause symbol, flashes when activated
10 TIMER: Remaining time in the active program in
minutes
11 Button lock active
12 Active program
5. INITIAL USE
Inserting the batteries
Open the battery compartment [4] by
pushing the cover in the area marked
with an arrow and sliding downwards.
Insert the three alkaline AAA 1.5 V bat-
teries. When inserting the batteries,
ensure that the correct polarity is ob-
served.
Then close the battery compartment
lid until you hear and feel it click into
place.
Connecting the connection
cable and positioning the
universal cu
1. Connect the connection cable with
the metallic connection clips on the
universal cu.
