User Manual for PF Freezers Beverage-Air
Rev. 12/20 Beverage-Air 7
CLEARANCE AND PLACEMENT
Placement
Consider the following when selecting a location for your freezer:
Clearance:
• 12 in. at the top
• 0.0 in. at the rear,
• 0.0 in. at the left side
• 0.0 in. at the right side
• 0.0 at the bottom
Floor Load: the oor on which the freezer is located must be even and level, free from vibrations, and strong enough to
support the combined weights of the unit and maximum product load.
Ventilation: Grille area at front must be free and clear of any object or wall.
Power Outlet: The installation of this appliance requires a dedicated power outlet located within the length of the unit's
power cord and be accessible for the purpose to disconnect power.
0" AT
BOTTOM
0" AT SIDES
12" AT
TOP
0" AT
REAR
