M 201 — Dynamic Moving-Coil Microphone 4
EN
TECHNICAL SPECIFICATIONS
Transducer type ................................ Dynamic
Operating principle ...................Pressure gradient
Polar pattern ..............................Hypercardioid
Frequency response ........................40 - 18,000 Hz
Rear attenuation at 1 kHz ..................> 20 dB at 120°
Sensitivity (0 dB = 1 V/Pa) .............1.2 mV/Pa (= -58 dBV)
Magnetic field suppression ..............> 18 dB at 50 Hz
Nominal impedance .............................. 200 Ω
Load impedance ................................≥ 1000 Ω
Diaphragm ..................................Hoaphan®
Case/finish .........................................Brass
Connector ..............................XLR, 3-pin, male
Dimensions:
Length ..........................................147 mm
Sha diameter ..................................24 mm
Head diameter ..................................24 mm
Weight .............................................228 g
FREQUENCY RESPONSE & POLAR PATTERN
This polar pattern and frequency response curve correspond to a typical production sample for this microphone.
Frequency response curve ± 2.5 dB M 201 0 dB = 1.2 mV/Pa
+20
+10
0 dB
-10
-20
-30
20 200 2k 20k100 1k 10k50 500 5k Hz
Sollfrequenzkurve ±2, 5dB
0 dB = 1, 2mV/Pa
M 201
-----
--
2cm Abstand
10cm Abstand
1m Abstand
+
+
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
300°
270°
210°
240°
180°
150°
120°
90°
60°
30°
0°
330°
-5dB
-10dB
-15dB
-20dB
WIRING DIAGRAM
ge
rt
3
1
2
APPLICATION
Whether in the udio or on age, the precise sound
and linear frequency response of the M 201 result in
a signal that consiently ands out in the mix and
leaves all po-processing options open. The M 201‘s
slim design also makes it easy to position the
microphone, giving the users the be possible
suppo in their search for the peect sound.
Due to its hypercardioid polar pattern and the
hum-bucking coil, the M 201 is ideal to successfully
avoid noise and feedback. In addition to this, crosalk
is reduced as be as possible. This is another reason
why this microphone is a popular companion for drums.
The M 201 is appreciated for the use with acouic
guitars because of its clear and detailed sound
reproduction. The M 201 can also be used for vocals
or speech.
+20
+10
0 dB
-10
-20
-30
20 200 2k 20k100 1k 10k50 500 5k Hz
Sollfrequenzkurve ±2, 5dB
0 dB = 1, 2mV/Pa
M 201
-----
--
2cm Abstand
10cm Abstand
1m Abstand
+
+
125 Hz
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
300°
270°
210°
240°
180°
150°
120°
90°
60°
30°
0°
330°
-5dB
-10dB
-15dB
-20dB
Diance 2 cm
Diance 10 cm
Diance 1 m
