MCS-D 3643 – Installation
25
english
Plane installation
For a plane installation under the table attach the mounting brackets with the supplied screws to the appropriate holes
in the housing. Refer to the picture below.
Make sure to use screws (not supplied) that are suitable for your furniture when installing the system unit under the
table.
Mounting bracket
Mounting bracket
