MIX 10 NG2 – RS 232 Interface
29
english
Cmd Data0 Data1 Command Data0 Data1
A7 00~1F
2
6
Bit 6
10~15 Change mic volume by “N”-steps
Higher or lower
N
0 = higher, 1 = lower
mic no
A8 00~02 Ducking manually 02 = on
00 = off
A9 00~01 10~15 Mic ducking
01 = enabled
00 = disabled
mic no
AA 00~01 01~02 Stereo ganged
01 = enabled
00 = disabled
01 = subgroup
02 = master
AB 00~03 00~01 Recall or save preset preset number
00 = recall
01 = save
AE 00~01 00~04,10~15 Mute channel
00= unmute
01 = mute
stereo / mic no
AF 01 Inquiry select line source
02 00~04 Inquiry stereo volume stereo no
03 10~15 Inquiry mic volume mic no
06 01~02 Inquiry stereo ganged 01 = subgroup , 02 = master
07 00~04,10~15 Inquiry mute state stereo / mic no
B0 00~7F Fade-out speed speed value
B1 00~7F Fade-in speed speed value
B2 00~7F Ducking threshold threshold value
B3 00~4F Ducking attenuation attenuation value
B4 00~7F Ducking hold value
B7 00~03 Switch-on status preset 1/2/3/switch-off
status(0)
B8 00 Reset EEPROM
BF 00 Inquiry fade-out speed
01 Inquiry fade-in speed
02 Inquiry ducking threshold value
03 Inquiry ducking stereo reduction
04 Inquiry ducking hold
05 Inquiry ducking fade-out speed
06 Inquiry ducking fade-in speed
07 Inquiry start configuration
08 Inquiry programmed version
“10” ~ “15” represent the channels MIC1~MIC6
“00”~ “04” represent the channels LINE, SUB-L, SUB-R, MASTER-L,MASTER-R.
Volume scale (hex):
00 ... 20 N x (-0.5 dB)
21 ... 40 N x (-1.0 dB) + 16.0 dB
41 ... 4E N x (-2.0 dB) + 80.0 dB
4F ... 7F -104 dB = mute
