6MMX 100
EN
CHANGING THE VOLUME
u The headphone volume can easily be increased
by turning the control wheel up.
u To decrease the volume, turn the control wheel
down.
Increase
volume
Decrease
volume
Turn counter-clockwise
and pull o.
Replace ear pad
and turn clockwise.
REPLACING THE EAR PADS
u To remove the ear pad, gently turn
it counter-clockwise and pull it o.
u To attach the ear pad, place it onto
the orange housing and gently turn it
clockwise until it sits tight.
TECHNICAL SPECIFICATIONS
Headphone
Transducer type . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dynamic
Operating principle . . . . . . . . . . . . . . . . . . . . . . . . . . . Closed
Sound coupling to the ear. . . . . . . . . . . . . . . Circumaural
Frequency response. . . . . . . . . . . . . . . . . . . . . 5 - 30,000 Hz
Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Ω
Max. sound pressure level
@1 mW / 500 Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . 116 dB SPL
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.5%
Headband pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5 N
Connection . . . . . . . . . . . 5-pole mini jack plug (3.5 mm)
Weight (headphone). . . . . . . . . . . . . . . . . . . 296 g (10.44 oz)
Microphone
Transducer type . . . . . . . . . . . . . . . . . . Electret condenser
Capsule diameter. . . . . . . . . . . . . . . . . . . . . . . 9.9 mm (0.39")
Polar pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cardioid
Frequency response . . . . . . . . . . . . . . . . . . . . . 5 - 18,000 Hz
Max. sound pressure level . . . . . . . . . . . . . . . . . . . . . . 118 dB
Signal-to-noise ratio. . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 dB
