MOD. BEZZERA B2013-C2013 Compact
3 – DESCRIPTION OF MACHINE
3.1 Description of operating cycle
The water coming from the water network through a motor pump adjusted at a pressure between 9 and 10
bar (0.9 – 1 MPa) goes through an over pressure valve adjusted at 12 bar (1.2 MPa), thus allowing to load
the boiler and the exchanger.
The boiler water, heated up through a resistor, heats up in turn the exchanger water from which, thanks to a
drip riser, is convoyed to the group in order to brew the coffee by means of a valve electronically controlled.
3.2.1 Description of command panels
(Fig. 06)
a Pre-selection key for regular coffee
b Pre-selection key for long coffee
c Pre-selection key for double dose of regular
coffee
d Pre-selection key for double dose of long cof-
fee
e Tea key
f Key for ongoing output/programming/stop
g Steam key
3.3 Technical data (Fig. 02)
C2013 Compact espresso coffee maker is built exclusively in the 2-group version.
B2013 espresso coffee maker is built in 1 or 3 group versions.
The 2 group version is described in this booklet; nonetheless, the instructions for use and the arrange-
ment of commands are also valid for the other versions.
The weighted sound pressure level A of the coffee machine is less than 70dB.
3.2 Description of commands
(Fig. 01 – Fig. 09)
1 Steam tap
2 Water key
3 keyboard for coffee/steam/water output
4 Steam nozzle
4a Automatic steam nozzle
5 Output of hot water
6 Threaded cap boiler
7 Filter holder
8 Red light
9 Orange light
10 ON switch
11 Pressure gauge
12 Blind filter
13 Filter 1 cup
14 Filter 2 cups
15 Green light
16 Drain basin
17 Body
B2013 B2013 C2013 B2013
1 GROUP 2 GROUPS 2 GROUPS Compact 3 GROUPS
Power supply V~/Hz 110 - 120 / 50-60Hz
Resistance V~ 110
Nominal power W 1600 2850 2050 3300
Resistance W 1400 2600 1800 3000
Power supply V~/Hz 220 - 400 / 50-60 Hz
Resistance V~ 230
Nominal power
W 2200 3250 2750 5300
Resistance W 2000 3000 2500 5000
Width “A” mm 570 750 600 960
Depth “B” mm 550 550 495 550
Height “C” mm 515 515 535 515
Net weight kg 49 54 63 75
Gross weight (pallet) kg 56 65 72 87
Load connection G 3/8”
Drain connection G 3/4”
