3 - MACHINE DESCRIPTION
3.1 Description of working cycle
The water coming from the tank on the back of the machine, via a pump, passes through a over
pressure valve regulated to 12 bar (1.2 MPa) and allows the boiler and the exchanger to be loaded.
The boiler water, heated up through a resistor, heats up the exchanger water from which, thanks to
a dip pipe, is convoyed to the group in order to brew the coffee by means of a valve electronically
controlled.
3.2 Description of controls
(Fig. 01 - Fig. 10)
1 Main switch
2 Green light
(PM)
2a Red light (
DEPID-PMPID
)
3 Yellow light
(PM)
4 a Coffee distribution button (PM
-PMPID
)
4 b Coffee distribution buttons
DEPID
)
4 c Coffee button LEDs (
DEPID
)
5 Distribution unit
6 Filter holder
7 Water tap
8 Hot water distributor
9 Steam tap
10 Steam nozzle
11 Gauge 0-15 bar (
DEPID-PMPID
)
11a Gauge dual scale (PM)
11b PID (
DEPID-PMPID
)
12 Electrical power cable
13 1 cup filter
14 2 cup filter
15 Blind filter
3.3 Technical data
(Fig. 02)
Power supply V~/Hz 220 – 240V~ / 50-60Hz 110 – 120V~ / 50-60Hz
Nominal power W 1400
Resistance W 1200
Boiler lt 1,5
Tank (S) lt 3
Width «A» mm 250
Depth «B» mm 450
Height «C» mm 375
Net weight kg 19
Gross weight (box) kg 22
