INSTALLATION MANUAL
TABLE “B”  LOGIC MENU - logic
Logic Denition
De-
fault
Cross
out
setting
used
Optional extras
TCA
Automatic Clo-
sing Time
0
0
Logic not enabled
1
Switches automatic closing on
STEP-BY-STEP
MOVEMNT
Step-by-step
movement
0
0
Inputs congured as Start E, Start I, Ped
operate with 4-step logic.
step-by-step mov.
3 STEP 4 STEP
CLOSED
OPENS
OPENS
DURING
CLOSING
STOPS
OPEN
CLOSES CLOSES
DURING
OPENING
STOP + TCA STOP + TCA
AFTER STOP OPENS OPENS
1
Inputs congured as Start E, Start I, Ped op-
erate with 3-step logic. Pulse during closing
reverses movement.
PRE-ALARM
Pre-alarm 0
0
The ashing light comes on at the same time as the motor(s) start.
1
The ashing light comes on approx. 3 seconds before the motor(s) start.
IBL OPEN
Block pulses
during opening
0
0
Pulse from inputs congured as Start E, Start I, Ped has eect during opening.
1
Pulse from inputs congured as Start E, Start I, Ped has no eect during opening.
SAFE 1
Conguration
of safety input
SAFE 1.
3-6
0
0 Input congured as Phot (photocell).
1 Input congured as Phot test (tested photocell).
2 Input congured as Phot op (photocell active during opening only).
3 Input congured as Phot op test (tested photocell active during opening only).
4 Input congured as Phot cl (photocell active during closing only).
5 Input congured as Phot cl test (tested photocell active during closing only).
AUX 3
Conguration of
AUX 3 output.
14-15
0
0 Output congured as 2nd Radio Channel.
1 Output congured as SCA (gate open light). In this case, the 2nd radio channel controls partial opening.
FIXED CODE
Fixed code
0
0
Receiver is congured for operation in rolling-code mode.
Fixed-Code Clones are not accepted.
1
Receiver is congured for operation in xed-code mode.
Fixed-Code Clones are accepted.
Prot.lev
Setting the
protection level
0
0
A - The password is not required to access the programming menus
B - Enables wireless memorizing of transmitters.
Operations in this mode are carried out near the control panel and do not require access:
- Press in sequence the hidden key and normal key (T1-T2-T3-T4) of a transmitter that has already been memo-
rized in standard mode via the radio menu.
- Press within 10 sec. the hidden key and normal key (T1-T2-T3-T4) of a transmitter to be memorized.
The receiver exits programming mode after 10 sec.: you can use this time to enter other new transmitters by
repeating the previous step.
C - Enables wireless automatic addition of clones.
Enables clones generated with the universal programmer and programmed Replays to be added to the
receiver’s memory.
D - Enables wireless automatic addition of replays.
Enables programmed Replays to be added to the receiver’s memory.
E - The board’s parameters can be edited via the U-link network
1
A - You are prompted to enter the password to access the programming menus
The default password is 1234.
No change in behaviour of functions B - C - D - E from 0 logic setting
2
A - You are prompted to enter the password to access the programming menus
The default password is 1234.
B - Wireless memorizing of transmitters is disabled.
C - Wireless automatic addition of clones is disabled. No change in behaviour of functions D - E from 0 logic setting
3
A - You are prompted to enter the password to access the programming menus
The default password is 1234.
B - Wireless memorizing of transmitters is disabled.
D - Wireless automatic addition of Replays is disabled.
No change in behaviour of functions C - E from 0 logic setting
4
A - You are prompted to enter the password to access the programming menus
The default password is 1234.
B - Wireless memorizing of transmitters is disabled.
C - Wireless automatic addition of clones is disabled.
D - Wireless automatic addition of Replays is disabled.
E - The option of editing the board’s parameters via the U-link network is disabled.
Transmitters are memorized only using the relevant Radio menu.
IMPORTANT: This high level of security stops unwanted clones from gaining access and also stops radio
interference, if any.
