BFT BOTTICELLI 800 U - Page 13

INSTALLATION MANUAL
ACCESS MENUS Fig. 1
x 2
autoset
Exit Menù
Conrm/
Switch on display
Scroll up
Scroll down
See PARAMETERS MENU
See LOGIC MENU
See RADIO MENU
add. start
hidden butt
hidden butt
release
release
desired button
desired button
Add. 2ch
erase 64
language
o
END
l.sw adj
VENERE D
ok
ok
ko
0--- 10-- 150- 1520
01 t1
PASSWORD
0--- 10-- 150- 1520 prg
Control unit software version
No. total manoeuvres
(x 10)
No. manoeuvres since latest
maintenance(x 10)
No. radio control devices
memorised
READ
35.40
Obstacle threshold
Instantaneous force motor
Diagnostics code DESCRIPTION NOTES
stre
START E input activated
STRI
START I input activated
STOP
STOP input activated
PHOT
PHOT input activated
SWO
OPENING LIMIT SWITCH input
activated
SWc
CLOSING LIMIT SWITCH input activated
ped
PEDESTRIAN input activated
open
OPEN input activated
CLS
CLOSE input activated
AMP
Reverse due to obstacle Check for obstacles in path
ER01
Photocell test failed Check photocell connection and/or logic settings
ER10
Board hardware test error Problems detected in motor’s control circuit
ER03
Photocell test failed (photocells active
only on opening)
Check photocell connection and/or logic settings
ER04
Photocell test failed (photocells active
only on closing)
Check safety edge connection and/or logic settings
ER11
Board hardware test error Problems detected in motor’s current reading circuit
***
*** Password entry.
Request with Protection Level
logic set to 1, 2, 3, 4
BOTTICELLI 800 U - 13
D812779 00100_08
ENGLISH
