BFT IGEA Installation Manual

ENGLISH
INSTALLATION MANUAL
relevant standards in force.
CAUTION! Excessive torque adjustment may jeopardise the anti-squash safety
function.Ontheotherhandinsucienttorqueadjustmentmaynotguarantee
correct opening or closing strokes.
10) EMERGENCY MANOEUVRE (Fig. 15)
In the case of power failure or operation malfunctions, manual emergency
manoeuvre can be carried out by turning the external release knob with per-
sonalised key.
First turn the key clockwise, then rotate the release knob to free the gate.
The knob is to be rotated anticlockwise in the case of a left-hand leaf, clockwise
in the case of a right-hand leaf.
Keep the knob in its release position by turning the key further. Push the leaf
slowly to open or close the gate.
To reactivate motor-driven operation, free the knob from its release position and
bring it back to its initial position for normal operation.
11) AUTOMATION CHECK
Before allowing the automation to be used normally, carry out the following
procedure very carefully:
• Checkthecorrectfunctioningofallsafetydevices(limitmicroswitches,
photocells, sensitive edges etc.).
• Checkthatthethrust(anti-squash)forceoftheleafiswithinthelimitssetby
current regulations.
• Checkthemanualopeningcommand.
• Checktheopeningandclosingoperationswiththecontroldevicesinuse.
• Checkthestandardandcustomisedelectronicfunctioninglogic.
12) AUTOMATION OPERATION
Since the automation can be remote-controlled by means of a remote control
device or a start button, and so out of sight, the good working order of all the
safety devices should be checked regularly. In the event of any anomalous fun-
ctioning of the safety devices, consult a specialised technician immediately. Keep
children at a safe distance from the automation operation area.
13) CONTROL
The automation is used for the power-operated opening and closing of the
gate. The control can be of a number of types (manual, remote-controlled, magnetic
badge access control, etc.) depending on requirements and the characteristics
of the installation. See the specic instructions for the various control systems.
Users of the automation must be instructed about its control and operation.
14) MAINTENANCE
Disconnect the power supply when carrying out any maintenance operations.
• LubricatetheIGEA-BTs of the manoeuvring arm regularly.
• Cleanthelensesofthephotocellseverysooften.
• Haveaspecialisedtechnician(installer)checktheadjustmentoftheelectric
clutch.
• Intheeventofanyanomalousfunctioningwhichcannotberesolved,discon-
nect the power supply and contact a specialised technician (installer). Whilst
the automation is out of order, activate the manual release to allow manual
opening and closing.
IGEA-BT -
11
D811369_09

BFT IGEA Specifications

General

Power Supply	230 V AC
Motor Voltage	24 V DC
Control Unit Power Supply	24 V DC
Locking	Electromechanical
Safety Devices	Photocells, safety edges
Release	Manual
Motor Type	24 V DC
Control Options	Remote Control, Keypad
