BGH GMV6 - Page 11

Model (integrated unit)
─
GMV-735WM/G-X GMV-785WM/G-X GMV-839WM/G-X
Model (single unit) GMV-680WM/G-X
GMV-335WM/
G-X+GMV-400WM/
G-X
GMV-335WM/
G-X+GMV-450WM/
G-X
GMV-335WM/
G-X+GMV-504WM/
G-X
Cooling capacity kW 68.0 73.5 78.5 83.9
Heating capacity kW 76.5 82.5 87.5 94.0
Noise dB(A) 65 64 64 65
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Compressor quantity Set 2 / / /
Refrigeration oil No. of
compressor
- FV68H / / /
Refrigeration
oil charge
Gross L 7.2 / / /
Compressor
charge
L 2.2 / / /
The others L 5 / / /
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW 20.50 7.70+9.20 7.70+10.80 7.70+12.3
Heating kW 20.10 7.80+9.50 7.80+10.70 7.80+12.9
Size(W×D×H) mm 1340×775×1690
930×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
28.6
Φ
31.8
Φ
31.8
Φ
31.8
Liquid pipe mm
Φ
15.9
Φ
19.05
Φ
19.05
Φ
19.05
Connection method Welding connection Welding connection Welding connection Welding connection
Net weight kg 355 220+290 220+290 220+295
Max. power kW 26.47 13.02+15.25 13.02+16.89 13.02+17.36
Minimum circuit current A 47.3 23.3+27.3 23.3+30.2 23.3+31.0
Max. fuse current A 50 25+32 25+32 25+40
Model (integrated unit) GMV-895WM/G-X GMV-950WM/G-X GMV-1015WM/G-X GMV-1064WM/G-X
Model (single unit)
GMV-280WM/G-X+
GMV-615WM/G-X
GMV-335WM/G-X+
GMV-615WM/G-X
GMV-400WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-560WM/G-X
Cooling capacity kW 89.5 95.0 101.5 106.4
Heating capacity kW 100.5 106.5 114.0 119.5
Noise dB(A) 65 66 66 66
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW 6.2+16.2 7.7+16.2 9.2+16.2 12.3+13.8
Heating kW 5.9+16.9 7.8+16.9 9.5+16.9 12.9+13.1
Size(S×D×H) mm
930×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
31.8
Φ
31.8
Φ
38.1
Φ
38.1
Liquid pipe mm
Φ
19.05
Φ
19.05
Φ
19.05
Φ
19.05
Connection method Welding connection Welding connection Welding connection Welding connection
Net weight
kg 215+350 220+350 290+350 295+350
Max. power kW 12.5+23.48 13.02+23.48 15.25+23.48 17.36+21.78
Min. circuit current A 22.4+42.0 23.3+42.0 27.3+42.0 31.0+38.9
Max. fuse current A 25+50 25+50 32+50 40+40
