BGH GMV6 - Unit Parameters

2
UNIT PARAMETERS
Model(integrated unit)
─ ─ ─ ─
Model(single unit) GMV-224WM/G-X GMV-280WM/G-X GMV-335WM/G-X GMV-400WM/G-X
Cooling capacity kW 22.4 28.0 33.5 40.0
Heating capacity kW 25.0 31.5 37.5 45.0
Noise dB(A) 58 60 63 63
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Compressor quantity set 1 1 1 1
Refrigeration oil No. of
compressor
- FV68H FV68H FV68H FV68H
Refrigeration
oil charge
Gross L 4.6 4.6 4.6 6.1
Compressor
charge
L 1.1 1.1 1.1 1.1
The others L 3.5 3.5 3.5 5
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW 5.00 6.20 7.70 9.20
Heating kW 4.80 5.90 7.80 9.50
Size(W×D×H) mm 930×775×1690 930×775×1690 930×775×1690 1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
19.05
Φ
22.2
Φ
25.4
Φ
25.4
Liquid pipe mm
Φ
9.52
Φ
9.52
Φ
12.7
Φ
12.7
Connection method Welding connection
Welding connection Welding connection Welding connection
Net weight kg 215 215 220 290
Max. power kW 11.10 12.50 13.02 15.25
Minimum circuit current A 19.9 22.4 23.3 27.3
Max. fuse current A 20 25 25 32
Model (integrated unit)
─ ─ ─ ─
Model (single unit) GMV-450WM/G-X GMV-504WM/G-X GMV-560WM/G-X GMV-615WM/G-X
Cooling capacity kW 45.0 50.4 56.0 61.5
Heating capacity kW 50.0 56.5 63.0 69.0
Noise dB(A) 63 63 63 64
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Compressor quantity Set 1 1 2 2
Refrigeration oil No. of
compressor
- FV68H FV68H FV68H FV68H
Refrigeration
oil charge
Gross L 6.1 6.1 7.2 7.2
Compressor
charge
L 1.1 1.1 2.2 2.2
The others L 5 5 5 5
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Rated power
Cooling kW 10.80 12.30 13.80 16.20
Heating kW 10.70 12.90 13.10 16.90
Size(W×D×H) mm 1340×775×1690 1340×775×1690 1340×775×1690 1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
28.6
Φ
28.6
Φ
28.6
Φ
28.6
Liquid pipe mm
Φ
12.7
Φ
15.9
Φ
15.9
Φ
15.9
Connection method Welding connection Welding connection Welding connection Welding connection
N
et weight kg 290 295 350 350
Max. power kW 16.89 17.36 21.78 23.48
Minimum circuit current A 30.2 31.0 38.9 42.0
Max. fuse current A 32 40 40 50
