NOTES:
a. Wired controller and remote dash receiver can be used at the same time.
b. When selecting remote dash receiver, select the remote controller.
c. Not suitable for GMV-ND22~140PLS/C-T.
10
EXTERNAL ELECTRICAL WIRING DIAGRAM
10.1 External wiring interface
External wiring interface
Power supply
Quantity 5
Logo L1 L2 L3 N PE
IDU/ODU communication
Quantity 2
Logo D1 D2
Central control
Quantity 2
Logo G1 G2
132
