4.3 Correction of capacity along with ambient temperature and
configuration ratio
Rectification of cooling capacity
：
GMV-224WM/G-X
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor
air temp
（℃ DB ）
Indoor air temp
14.0 ℃ WB 17.0 ℃ WB 18.0 ℃ WB 19.0 ℃ WB 20.0 ℃ WB 22.0 ℃ WB 24.0 ℃ WB
20.0 ℃ DB 24.0 ℃ DB 26.0℃ DB 27.0 ℃ DB 28.0 ℃ DB 30.0 ℃ DB 32.0 ℃ DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
135%
-5 19.82 2.22 23.60 2.70 28.01 2.74 28.44 2.74 28.95 2.76 30.67 2.80 30.43 2.83
0 19.82 2.22 23.60 2.71 28.01 2.74 28.44 2.74 28.95 2.77 30.67 2.80 30.43 2.83
4 19.82 2.23 23.60 2.72 28.01 2.75 28.44 2.75 28.95 2.78 30.67 2.81 30.43 2.84
7 19.82 2.27 23.60 2.77 28.01 2.80 28.44 2.81 28.95 2.83 30.41 2.86 30.43 2.89
10 19.82 2.31 23.60 2.83 28.01 3.36 28.44 3.42 28.76 3.37 29.50 3.23 30.21 3.08
12 19.82 2.35 23.60 2.88 28.01 3.43 28.03 3.40 28.44 3.35 29.09 3.20 29.81 3.15
14 19.82 2.40 23.60 2.94 27.93 3.47 27.71 3.39 28.03 3.33 28.77 3.30 29.48 3.34
16 19.82 2.44 23.60 3.00 27.60 3.46 27.31 3.42 27.63 3.44 28.36 3.48 29.08 3.51
18 19.82 2.49 23.60 3.06 27.19 3.59
26.91 3.59 27.31 3.63 28.03 3.66 28.76 3.69
20 19.82 2.54 23.60 3.25 26.78 3.76 26.58 3.77 26.91 3.80 27.63 3.84 28.36 3.88
21 19.82 2.61 23.60 3.37 26.61 3.85 26.42 3.85 26.75 3.89 27.47 3.93 28.20 3.96
23 19.82 2.80 23.60 3.61 26.28 4.03 26.02 4.03 26.34 4.07 27.07 4.11 27.79 4.15
25 19.82 2.99 23.60 3.87 25.87 4.20 25.70 4.20 26.02 4.25 26.75 4.29 27.47 4.33
27 19.82 3.19 23.60 4.14 25.54 3.70 25.30 4.39 25.62 4.42 26.34 4.47 27.07 4.52
29 19.82 3.41 23.60 4.42 25.13 4.55 24.89 4.56 25.30 4.61 26.02 4.65 26.75 4.70
31 19.82 3.64 23.52 4.68 24.72 4.74 24.57 4.74 24.89 4.78 25.62 4.84 26.34 4.89
33 19.82 3.88 23.12 4.86 24.39 4.90 24.17 4.92 24.57 4.97 25.30 5.02 25.94 5.08
35 19.82 4.13 22.72 5.03 23.98 5.09 23.85 5.10 24.17 5.15 24.89 5.21 25.62 5.26
37 19.82 4.40 22.40 5.22 23.65 5.28 23.87 5.28 23.89 5.34 24.49 5.40 25.22 5.46
39 19.82 4.68 21.99 5.39 23.23 5.45 23.87 5.46 24.07 5.52 24.17 5.58 24.89 5.65
41 19.82 5.21 22.72 6.34 23.98 6.42 23.85 5.92 23.91 5.97 24.05 6.04 24.41 6.11
43 19.82 5.43 23.47 6.61 24.08 6.77 23.82 6.29 23.76 6.20 24.10
6.19 23.93 6.26
44 19.19 5.66 22.31 6.90 23.09 7.13 23.42 6.18 23.74 6.43 23.97 6.35 24.08 6.42
46 18.20 7.33 21.37 8.22 22.49 7.37 22.63 6.58 23.12 6.71 23.34 6.67 23.56 6.74
47 17.71 8.16 20.90 8.89 22.19 7.49 22.23 6.78 22.80 6.85 23.02 6.82 23.30 6.89
50 15.10 7.91 18.28 8.76 19.77 7.90 20.18 7.35 20.92 7.31 21.73 7.29 22.18 7.21
52 9.62 4.76 12.94 5.93 16.01 6.67 17.63 7.00 17.71 6.77 18.14 6.68 19.16 6.86
53 8.01 3.96 10.65 4.87 13.97 5.82 15.24 6.05 15.50 5.92 16.10 5.93 16.69 5.97
55 7.49 3.71 9.71 4.44 12.69 5.28 13.46 5.34 14.05 5.37 14.73 5.42 15.41 5.52
16
