Combination
Outdoor
air temp
（℃ DB ）
Indoor air temp
14.0 ℃ WB 17.0℃ WB 18.0℃ WB 19.0℃ WB 20.0℃ WB 22.0℃ WB 24.0℃ WB
20.0 ℃ DB 24.0 ℃ DB 26.0 ℃ DB 27.0 ℃ DB 28.0 ℃ DB 30.0 ℃ DB 32.0 ℃ DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90%
-5 17.1 1.65 20.4 2.08 23.7 2.57 25.4 2.84 27.0 3.13 30.3 3.35 33.6 3.38
0 17.1 1.65 20.4 2.09 23.7 2.58 25.4 2.85 27.0 3.13 30.3 3.35 33.6 3.38
4 17.1 1.66 20.4 2.10 23.7 2.59 25.4 2.86 27.0 3.14 30.3 3.37 33.6 3.40
7 17.1 1.69 20.4 2.13 23.7 2.64 25.4 2.91 27.0 3.20 30.3 3.43 33.6 3.46
10 17.1 1.87 20.4 2.24 23.7 2.62 25.4 2.96 27.0 3.15 30.4 3.61 33.6 4.09
12 17.1 1.89 20.4 2.27 23.7 2.66 25.4 3.00 27.0 3.21 30.4 3.67 33.6 4.14
14 17.1 1.92 20.4 2.31 23.7 2.71 25.4 3.04 27.0 3.26 30.4 3.73 33.6 4.21
16 17.1 1.97 20.4 2.36 23.7 2.77 25.4 3.11 27.0 3.34 30.4 3.82 33.5 4.29
18 17.1 2.01 20.4 2.42 23.7 2.82
25.4 3.17 27.0 3.40 30.4 3.91 33.2 4.45
20 17.1 2.04 20.4 2.45 23.7 2.91 25.4 3.24 27.0 3.54 30.4 4.20 32.6 4.63
21 17.1 2.06 20.4 2.48 23.7 3.01 25.4 3.34 27.0 3.67 30.4 4.34 32.4 4.73
23 17.1 2.12 20.4 2.65 23.7 3.24 25.4 3.59 27.0 3.92 30.4 4.66 31.9 4.98
25 17.1 2.25 20.4 2.82 23.7 3.45 25.4 3.84 27.0 4.20 30.4 4.99 31.5 5.18
27 17.1 2.40 20.4 3.01 23.7 3.70 25.4 4.09 27.0 4.49 30.4 5.32 31.0 5.41
29 17.1 2.55 20.4 3.21 23.7 3.95 25.4 4.37 27.0 4.80 30.0 5.58 30.6 5.63
31 17.1 2.71 20.4 3.42 23.7 4.22 25.4 4.67 27.0 5.12 29.5 5.78 30.1 5.86
33 17.1 2.88 20.4 3.64 23.7 4.49 25.4 4.97 27.0 5.45 29.1 6.01 29.7 6.07
35 17.1 3.07 20.4 3.88 23.7 4.79 25.4 5.29 27.0 5.82 28.6 6.23 29.2 6.29
37 17.1 3.27 20.4 4.13 23.7 5.10 24.9 5.49 27.0 6.23 28.1 6.46 28.8 6.44
39 17.1 3.48 20.4 4.40 23.7 5.43 24.6 5.67 27.0 6.61 27.7 6.69 28.3 6.68
41 16.2 3.86 19.4 4.89 22.6 6.04 24.1 6.14 25.7 6.76 27.2 7.23 27.8 7.29
43 15.3 4.03 18.4 5.10 22.0 6.37 23.7 6.53 25.2 7.01 26.8
7.41 27.4 7.49
44 15.1 4.20 18.4 5.32 21.5 6.71 23.1 6.94 24.7 7.28 26.2 7.60 26.9 7.67
46 14.5 5.1 17.9 6.5 21.0 6.9 22.6 7.0 24.1 7.6 25.6 8.0 26.3 8.0
47 14.2 5.59 17.7 7.08 20.8 7.04 22.3 7.04 23.8 7.75 25.3 8.16 26.0 8.24
50 13.0 5.49 15.9 6.95 18.5 7.43 19.9 7.62 21.2 8.27 22.6 8.72 23.4 8.61
52 10.2 4.53 13.8 5.64 17.0 6.35 18.8 6.66 18.9 6.44 19.5 6.36 20.4 6.53
53 8.5 3.77 11.3 4.64 14.9 5.54 16.2 5.76 16.5 5.64 17.3 5.64 17.8 5.69
55 8.0 3.53 10.3 4.23 13.5 5.03 14.3 5.09 15.0 5.11 15.9 5.16 16.4 5.25
80%
-5 15.2 1.42 18.1 1.75 21.1 2.18 22.6 2.40 24.0 2.62 27.0 3.11 29.9 3.34
0 15.2 1.42 18.1 1.76 21.1 2.18 22.6 2.40 24.0 2.63 27.0 3.12 29.9 3.34
4 15.2 1.43 18.1 1.76 21.1 2.19 22.6 2.41 24.0 2.64 27.0 3.13 29.9 3.36
7 15.2 1.46 18.1 1.80 21.1 2.23 22.6 2.46 24.0 2.69 27.0 3.19 29.9 3.42
10 15.2 1.70 18.1 2.03 21.1 2.39 22.6 2.57 24.0 2.76 27.0 3.15 29.9 3.66
12 15.2 1.72 18.1 2.06 21.1 2.43 22.6 2.62 24.0 2.81 27.0 3.20 29.9 3.63
14 15.2
1.75 18.1 2.11 21.1 2.47 22.6 2.67 24.0 2.86 27.0 3.26 29.9 3.71
16 15.2 1.78 18.1 2.14 21.1 2.52 22.6 2.72 24.0 2.90 27.0 3.33 29.9 3.84
18 15.2 1.81 18.1 2.18 21.1 2.58 22.6 2.77 24.0 2.96 27.0 3.41 29.9 4.11
20 15.2 1.85 18.1 2.22 21.1 2.62 22.6 2.82 24.0 3.03 27.0 3.53 29.9 4.26
21 15.2 1.86 18.1 2.24 21.1 2.65 22.6 2.86 24.0 3.09 27.0 3.66 29.9 4.56
23 15.2 1.90 18.1 2.29 21.1 2.77 22.6 3.04 24.0 3.31 27.0 3.91 29.9 4.88
25 15.2 1.96 18.1 2.43 21.1 2.97 22.6 3.25 24.0 3.53 27.0 4.19 29.9 5.20
27 15.2 2.08 18.1 2.59 21.1 3.16 22.6 3.47 24.0 3.79 27.0 4.47 29.9 5.39
29 15.2 2.21 18.1 2.76 21.1 3.37 22.6 3.69 23.9 4.04 27.0 4.77 29.9 5.58
31 15.2 2.35 18.1 2.93 21.1 3.58 22.6 3.94 23.9 4.31 27.0 5.09 29.4 5.79
33 15.2 2.50 18.1 3.27 21.1 3.82 22.6 4.19 23.9 4.59 27.0 5.43 29.0 6.00
35 15.2 2.65 18.1 3.27 21.1 4.06 22.6 4.47 23.9 4.89 27.0 5.80 28.5 6.21
37 15.2 2.81 18.1 3.52 21.1 4.32 22.2 4.76 23.9 5.20 27.0 6.18 28.1 6.44
39 15.2 2.97 18.1 3.73 21.1 4.60
21.9 5.07 23.9 5.54 27.0 6.58 27.6 6.68
41 14.4 3.34 17.2 4.12 20.1 5.12 21.4 5.19 22.8 5.67 25.7 6.73 27.2 7.21
43 13.6 3.48 16.7 4.30 19.5 5.39 21.0 5.51 22.3 5.88 25.2 6.90 26.7 7.39
44 13.4 3.63 16.3 4.48 19.1 5.69 20.5 5.86 21.8 6.11 24.7 7.08 26.2 7.58
46 12.9 4.4 16.0 5.5 18.7 5.9 20.0 5.9 21.3 6.4 24.2 7.4 25.6 8.0
47 12.6 4.83 15.8 5.96 18.5 5.97 19.8 5.95 21.1 6.50 23.9 7.60 25.4 8.14
50 11.6 4.74 14.1 5.85 16.5 6.29 17.7 6.44 18.8 6.94 21.3 8.12 22.8 8.51
52 9.1 3.82 12.2 4.76 15.1 5.35 16.7 5.62 16.8 5.44 17.2 5.36 18.1 5.51
53 7.6 3.18 10.1 3.91 13.2 4.67 14.4 4.86 14.7 4.76 15.2 4.76 15.8 4.80
55 7.1 2.98 9.2 3.57 12.0 4.24 12.7 4.29 13.3 4.31 13.9 4.36 14.6 4.43
GMV6 DC Inverter VRF Units Technical Sales Guide
23
