GMV-504WM/G-X
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor
air temp
（℃ DB ）
Indoor air temp
14.0 ℃ WB 17.0℃ WB 18.0℃ WB 19.0 ℃ WB 20.0 ℃ WB 22.0 ℃ WB 24.0 ℃ WB
20.0 ℃ DB 24.0 ℃ DB 26.0 ℃ DB 27.0 ℃ DB 28.0 ℃ DB 30.0 ℃ DB 32.0 ℃ DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
135%
-5 44.6 5.44 53.1 6.62 61.6 6.70 64.0 6.74 65.1 6.77 66.8 6.85 68.5 6.93
0 44.6 5.45 53.1 6.64 61.6 6.72 64.0 6.75 65.1 6.79 66.8 6.87 68.5 6.94
4 44.6 5.47 53.1 6.66 61.6 6.74 64.0 6.78 65.1 6.81 66.8 6.89 68.5 6.96
7 44.6 5.57 53.1 6.78 61.6 6.87 64.0 6.90 65.1 6.94 66.8 7.02 68.5 7.09
10 44.6 5.67 53.1 6.93 61.6 8.24 64.0 8.42 64.7 8.26 66.3 7.91 68.0 7.54
12 44.6 5.77 53.1 7.06 61.6 8.40 63.1 8.37 64.0 8.21 65.4 7.84 67.1 7.72
14 44.6 5.88 53.1 7.19 61.4 8.50 62.4 8.34 63.1 8.16 64.7 8.09 66.3 8.17
16 44.6 5.98 53.1 7.34 60.7 8.47 61.4 8.40 62.2 8.44 63.8 8.52 65.4 8.60
18 44.6 6.10 53.1 7.49 59.8 8.79
60.5 8.84 61.4 8.89 63.1 8.97 64.7 9.05
20 44.6 6.23 53.1 7.97 58.9 9.22 59.8 9.27 60.5 9.32 62.2 9.40 63.8 9.50
21 44.6 6.40 53.1 8.26 58.5 9.43 59.5 9.48 60.2 9.53 61.8 9.63 63.4 9.71
23 44.6 6.86 53.1 8.85 57.8 9.86 58.5 9.91 59.3 9.96 60.9 10.06 62.5 10.16
25 44.6 7.33 53.1 9.48 56.9 10.29 57.8 10.34 58.5 10.41 60.2 10.51 61.8 10.61
27 44.6 7.82 53.1 10.15 56.2 9.07 56.9 10.79 57.6 10.84 59.3 10.96 60.9 11.07
29 44.6 8.35 53.1 10.84 55.3 11.16 56.0 11.22 56.9 11.29 58.5 11.40 60.2 11.52
31 44.6 8.92 52.9 11.47 54.4 11.60 55.3 11.67 56.0 11.72 57.6 11.85 59.3 11.99
33 44.6 9.50 52.0 11.90 53.7 12.02 54.4 12.10 55.3 12.17 56.9 12.30 58.4 12.45
35 44.6 10.13 51.1 12.33 52.7 12.48 53.7 12.55 54.4 12.61 56.0 12.76 57.6 12.90
37 44.6 10.77 50.4 12.78 52.0 12.93 52.7 13.00 53.7 13.08 55.1 13.23 56.7 13.38
39 44.6 11.47 49.5 13.21 51.1 13.36 52.0 13.44 52.7 13.53 54.4 13.68 56.0 13.84
41 42.1 12.76 48.6 15.54 50.1 15.73 51.0 14.56 51.7 14.63 53.3 14.81 54.9 14.96
43 39.8 13.31 47.7 16.20 49.1 16.58 50.0 15.47 50.7 15.19 52.3
15.18 53.9 15.34
44 39.2 13.88 46.0 16.90 47.7 17.48 48.8 16.44 49.6 15.77 51.3 15.57 53.0 15.73
46 37.8 16.9 45.0 20.6 46.7 18.1 47.7 16.6 48.5 16.4 50.1 16.3 51.9 16.5
47 37.0 18.46 44.5 22.48 46.2 18.35 47.1 16.69 47.9 16.78 49.6 16.72 51.3 16.89
50 33.9 18.13 39.9 22.08 41.2 19.35 42.0 18.07 42.7 17.91 44.2 17.87 46.1 17.67
52 21.7 10.73 29.1 13.36 36.0 15.03 39.7 15.78 39.9 15.26 40.8 15.06 43.1 15.46
53 18.0 8.93 24.0 10.99 31.4 13.11 34.3 13.65 34.9 13.35 36.2 13.36 37.6 13.47
55 16.9 8.36 21.8 10.02 28.6 11.91 30.3 12.05 31.6 12.11 33.1 12.23 34.7 12.44
120%
-5 41.1 4.84 48.9 6.27 56.9 6.66 60.9 6.69 64.1 6.73 65.5 6.80 67.0 6.87
0 41.1 4.85 48.9 6.28 56.9 6.67 60.9 6.71 64.1 6.74 65.5 6.81 67.0 6.88
4 41.1 4.87 48.9 6.30 56.9 6.70 60.9 6.73 64.1 6.77 65.5 6.84 67.0 6.91
7 41.1 4.96 48.9 6.42 56.9 6.82 60.9 6.86 64.1 6.89 65.5 6.97 67.0 7.04
10 41.1 5.17 48.9 6.32 56.9 7.51 60.9 8.12 63.8 8.47 65.3 8.14 66.7 7.82
12 41.1 5.27 48.9 6.43 56.9 7.66 60.9 8.27 62.9 8.42 64.3 8.11 65.8 7.77
14 41.1
5.37 48.9 6.56 56.9 7.81 60.9 8.44 62.0 8.37 63.6 8.06 65.1 8.11
16 41.1 5.47 48.9 6.70 56.9 7.96 60.5 8.50 61.3 8.39 62.7 8.47 64.2 8.54
18 41.1 5.57 48.9 6.83 56.9 8.24 59.6 8.79 60.4 8.82 61.8 8.90 63.4 8.98
20 41.1 5.69 48.9 7.09 56.9 8.85 58.9 9.22 59.6 9.25 61.1 9.33 62.5 9.42
21 41.1 5.74 48.9 7.34 56.9 9.17 58.4 9.43 59.1 9.47 60.7 9.55 62.2 9.65
23 41.1 6.13 48.9 7.87 56.9 9.81 57.6 9.85 58.4 9.90 59.8 10.00 61.3 10.08
25 41.1 6.55 48.9 8.42 56.0 10.24 56.7 10.28 57.5 10.33 59.1 10.43 60.5 10.53
27 41.1 7.00 48.9 9.00 55.3 10.66 56.0 10.73 56.7 10.77 58.2 10.87 59.6 10.97
29 41.1 7.46 48.9 9.61 54.4 11.09 55.1 11.16 55.8 11.21 57.3 11.32 58.9 11.42
31 41.1 7.96 48.9 10.26 53.7 11.54 54.4 11.59 55.1 11.65 56.6 11.77 58.0 11.89
33 41.1 8.47 48.9 10.96 52.7 11.97 53.5 12.03 54.2 12.08 55.6 12.22 57.1 12.33
35 41.1 9.02 48.9 11.67 51.8 12.40 52.6 12.47 53.5 12.53 54.9 12.66 56.4 12.80
37 41.1 9.60 48.9 12.43 51.1 12.85 51.8 12.91 52.6 12.98 54.0 13.11 55.5 13.26
39 41.1 10.21 48.8 13.13 50.2 13.28
50.9 13.36 51.7 13.43 53.3 13.58 54.7 13.71
41 38.9 11.36 46.5 14.70 49.3 15.62 50.0 14.46 50.9 14.54 52.3 14.69 53.7 14.84
43 36.7 11.84 44.3 15.33 48.3 16.46 49.0 15.36 50.1 15.09 51.3 15.06 52.7 15.23
44 36.2 12.35 44.0 15.99 46.9 17.36 47.8 16.33 48.8 15.67 50.3 15.45 51.9 15.61
46 34.8 15.1 43.1 19.5 45.9 17.9 46.7 16.5 47.6 16.3 49.2 16.2 50.7 16.4
47 34.2 16.44 42.6 21.27 45.4 18.23 46.2 16.58 47.1 16.67 48.6 16.59 50.2 16.76
50 31.3 16.14 38.2 20.89 40.5 19.22 41.2 17.95 42.0 17.80 43.4 17.73 45.1 17.53
52 21.2 10.66 28.5 13.27 35.3 14.93 38.9 15.68 39.0 15.16 40.0 14.96 42.2 15.36
53 17.6 8.87 23.5 10.91 30.8 13.03 33.6 13.56 34.2 13.27 35.5 13.27 36.8 13.38
55 16.5 8.30 21.4 9.95 28.0 11.84 29.7 11.97 31.0 12.03 32.5 12.15 34.0 12.35
GMV6 DC Inverter VRF Units Technical Sales Guide
41
