Combination
Outdoor
air temp
（℃ DB ）
Indoor air temp
14.0 ℃ WB 17.0 ℃ WB 18.0 ℃ WB 19.0 ℃ WB 20.0 ℃ WB 22.0 ℃ WB 24.0 ℃ WB
20.0 ℃ DB 24.0 ℃ DB 26.0 ℃ DB 27.0 ℃ DB 28.0 ℃ DB 30.0 ℃ DB 32.0 ℃ DB
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90%
-5 30.8 3.27 36.7 4.13 42.7 5.10 45.7 5.64 48.6 6.20 54.6 6.64 60.5 6.70
0 30.8 3.27 36.7 4.14 42.7 5.11 45.7 5.65 48.6 6.22 54.6 6.65 60.5 6.71
4 30.8 3.28 36.7 4.16 42.7 5.13 45.7 5.67 48.6 6.24 54.6 6.68 60.5 6.74
7 30.8 3.35 36.7 4.24 42.7 5.23 45.7 5.78 48.6 6.36 54.6 6.80 60.5 6.86
10 30.8 3.70 36.7 4.45 42.7 5.21 45.7 5.87 48.6 6.25 54.6 7.16 60.5 8.11
12 30.8 3.75 36.7 4.51 42.7 5.28 45.7 5.94 48.6 6.37 54.6 7.28 60.5 8.21
14 30.8 3.82 36.7 4.58 42.7 5.37 45.7 6.03 48.6 6.48 54.6 7.41 60.5 8.35
16 30.8 3.90 36.7 4.69 42.7 5.49 45.7 6.17 48.6 6.62 54.6 7.57 60.3 8.51
18 30.8 3.99 36.7 4.79 42.7 5.59
45.7 6.29 48.6 6.75 54.6 7.75 59.8 8.82
20 30.8 4.05 36.7 4.87 42.7 5.78 45.7 6.42 48.6 7.03 54.6 8.33 58.7 9.19
21 30.8 4.09 36.7 4.91 42.7 5.98 45.7 6.63 48.6 7.27 54.6 8.61 58.4 9.39
23 30.8 4.20 36.7 5.25 42.7 6.43 45.7 7.13 48.6 7.79 54.6 9.25 57.5 9.88
25 30.8 4.46 36.7 5.59 42.7 6.84 45.7 7.61 48.6 8.33 54.6 9.89 56.7 10.28
27 30.8 4.77 36.7 5.97 42.7 7.34 45.7 8.12 48.6 8.92 54.6 10.56 55.8 10.73
29 30.8 5.05 36.7 6.38 42.7 7.85 45.7 8.68 48.6 9.52 54.0 11.06 55.1 11.16
31 30.8 5.38 36.7 6.79 42.7 8.36 45.7 9.26 48.6 10.16 53.1 11.47 54.2 11.62
33 30.8 5.72 36.7 7.23 42.7 8.92 45.7 9.85 48.6 10.80 52.4 11.93 53.5 12.04
35 30.8 6.08 36.7 7.70 42.7 9.51 45.7 10.50 48.6 11.55 51.5 12.36 52.6 12.47
37 30.8 6.48 36.7 8.20 42.7 10.12 44.9 10.88 48.6 12.36 50.6 12.81 51.8 12.77
39 30.8 6.90 36.7 8.73 42.7 10.78 44.3 11.24 48.6 13.11 49.8 13.28 50.9 13.25
41 29.1 7.66 34.9 9.70 40.6 11.98 43.4 12.18 46.2 13.40 49.0 14.34 50.1 14.47
43 27.5 7.99 33.1 10.11 39.5 12.63 42.6 12.95 45.3 13.92 48.2
14.71 49.3 14.87
44 27.1 8.33 33.0 10.55 38.7 13.31 41.6 13.76 44.4 14.44 47.2 15.08 48.4 15.22
46 26.1 10.2 32.3 12.9 37.8 13.8 40.6 13.9 43.3 15.1 46.1 15.8 47.3 16.0
47 25.6 11.09 31.9 14.04 37.4 13.97 40.1 13.97 42.8 15.37 45.6 16.20 46.8 16.34
50 23.4 10.89 28.6 13.78 33.4 14.73 35.8 15.13 38.2 16.41 40.7 17.31 42.1 17.09
52 18.4 8.99 24.8 11.19 30.7 12.59 33.8 13.22 33.9 12.78 35.2 12.61 36.7 12.95
53 15.3 7.48 20.4 9.20 26.8 10.98 29.2 11.43 29.7 11.18 31.2 11.19 32.0 11.28
55 14.4 7.00 18.6 8.39 24.3 9.98 25.8 10.09 26.9 10.14 28.6 10.24 29.5 10.42
80%
-5 27.4 2.82 32.6 3.48 38.0 4.33 40.6 4.76 43.1 5.21 48.6 6.18 53.8 6.62
0 27.4 2.83 32.6 3.49 38.0 4.33 40.6 4.77 43.1 5.21 48.6 6.19 53.8 6.63
4 27.4 2.84 32.6 3.50 38.0 4.35 40.6 4.79 43.1 5.23 48.6 6.21 53.8 6.66
7 27.4 2.89 32.6 3.56 38.0 4.43 40.6 4.88 43.1 5.33 48.6 6.33 53.8 6.78
10 27.4 3.37 32.6 4.03 38.0 4.74 40.6 5.11 43.2 5.47 48.6 6.25 53.8 7.25
12 27.4 3.41 32.6 4.09 38.0 4.82 40.6 5.21 43.2 5.57 48.6 6.35 53.8 7.20
14 27.4
3.48 32.6 4.18 38.0 4.91 40.6 5.29 43.2 5.67 48.6 6.46 53.8 7.36
16 27.4 3.53 32.6 4.24 38.0 5.01 40.6 5.39 43.2 5.76 48.6 6.61 53.8 7.62
18 27.4 3.60 32.6 4.33 38.0 5.12 40.6 5.50 43.2 5.87 48.6 6.76 53.8 8.15
20 27.4 3.66 32.6 4.41 38.0 5.21 40.6 5.60 43.2 6.00 48.6 7.00 53.8 8.45
21 27.4 3.70 32.6 4.44 38.0 5.25 40.6 5.67 43.2 6.14 48.6 7.26 53.8 9.05
23 27.4 3.76 32.6 4.54 38.0 5.50 40.6 6.03 43.2 6.57 48.6 7.76 53.8 9.68
25 27.4 3.88 32.6 4.82 38.0 5.88 40.6 6.45 43.2 7.01 48.6 8.31 53.8 10.33
27 27.4 4.13 32.6 5.14 38.0 6.27 40.6 6.88 43.2 7.52 48.6 8.87 53.8 10.69
29 27.4 4.39 32.6 5.47 38.0 6.68 40.6 7.33 43.1 8.02 48.6 9.47 53.8 11.08
31 27.4 4.66 32.6 5.82 38.0 7.11 40.6 7.81 43.1 8.55 48.6 10.10 52.9 11.48
33 27.4 4.96 32.6 6.48 38.0 7.58 40.6 8.32 43.1 9.10 48.6 10.78 52.2 11.90
35 27.4 5.25 32.6 6.48 38.0 8.06 40.6 8.87 43.1 9.69 48.6 11.51 51.3 12.33
37 27.4 5.57 32.6 6.98 38.0 8.57 39.9 9.44 43.1 10.32 48.6 12.25 50.6 12.78
39 27.4 5.90 32.6 7.41 38.0 9.12
39.3 10.06 43.1 10.99 48.6 13.05 49.7 13.26
41 25.9 6.62 31.0 8.17 36.1 10.15 38.6 10.29 41.0 11.24 46.2 13.35 48.9 14.30
43 24.5 6.90 30.1 8.52 35.2 10.69 37.9 10.94 40.1 11.67 45.3 13.69 48.1 14.67
44 24.1 7.20 29.4 8.88 34.4 11.28 36.9 11.62 39.3 12.12 44.5 14.04 47.2 15.04
46 23.2 8.8 28.7 10.8 33.6 11.7 36.1 11.7 38.4 12.6 43.5 14.7 46.2 15.8
47 22.7 9.58 28.4 11.82 33.2 11.84 35.6 11.79 37.9 12.89 43.0 15.07 45.7 16.15
50 20.8 9.41 25.4 11.60 29.7 12.49 31.8 12.77 33.8 13.76 38.4 16.11 41.0 16.89
52 16.4 7.58 22.0 9.44 27.3 10.62 30.0 11.15 30.2 10.79 30.9 10.64 32.6 10.93
53 13.6 6.31 18.1 7.76 23.8 9.27 26.0 9.65 26.4 9.44 27.4 9.44 28.4 9.52
55 12.8 5.91 16.5 7.08 21.6 8.42 22.9 8.51 23.9 8.56 25.1 8.64 26.2 8.79
GMV6 DC Inverter VRF Units Technical Sales Guide
43
