BGH GMV6 - Page 85

50%
-19.8 -20.0 29.0 12.56 27.1 11.58 25.2 10.40 24.3 10.07 23.4 9.68 21.8 8.99
-18.8 -19.0 29.0 12.30 27.1 11.35 25.3 10.21 24.3 9.86 23.4 9.49 21.8 8.81
-16.7 -17.0 29.1 11.75 27.2 10.85 25.3 9.78 24.3 9.45 23.4 9.11 21.8 8.45
-13.7 -15.0 29.1 11.20 27.2 10.35 25.3 9.34 24.4 9.04 23.5 8.70 21.8 8.06
-11.8 -13.0 29.1 10.64 27.2 9.86 25.3 8.89 24.4 8.60 23.5 8.28 21.8 7.68
-9.8 -11.0 29.2 10.09 27.3 9.34 25.4 8.46 24.4 8.18 23.5 7.88 21.8 7.30
-9.5 -10.0 29.2 9.82 27.3 9.09 25.4 8.25 24.4 7.98 23.5 7.68 21.8 7.11
-8.5 -9.1 29.2 9.58 27.3 8.88 25.4 8.04 24.4 7.79 23.5 7.51 21.8 6.95
-7.0 -7.6 29.1 9.16 27.2 8.53 25.3 7.71 24.4 7.47 23.5 7.20 21.8 6.69
-5.0 -5.6 28.9 8.59 27.1 7.98 25.2 7.26 24.2 7.03 23.4 6.81 21.8 6.33
-3.0 -3.7 28.9 8.14 27.1 7.56 25.2 6.89 24.2 6.67 23.4 6.46 21.8 6.02
0.0 -0.7 28.9 7.47 27.1 6.95 25.2 6.35 24.2 6.15 23.4 5.96 21.8 5.57
3.0 2.2 28.9 6.88 27.1 6.40 25.2 5.86 24.2 5.68 23.4 5.52 21.8 5.16
5.0 4.1 28.9 6.53 27.1 6.07 25.2 5.57 24.2 5.41 23.4 5.25 21.8 4.90
7.0 6.0 28.9
6.19 27.1 5.77 25.2 5.31 24.2 5.14 23.4 5.00 21.8 4.68
9.0 7.9 28.9 5.88 27.1 5.49 25.2 5.05 24.2 4.91 23.4 4.76 21.8 4.46
11.0 9.8 28.9 5.59 27.1 5.22 25.2 4.81 24.2 4.68 23.4 4.54 21.8 4.26
13.0 11.8 28.9 5.31 27.1 4.96 25.2 4.58 24.2 4.46 23.4 4.32 21.8 4.06
15.0 13.7 28.9 5.06 27.1 4.74 25.2 4.38 24.2 4.25 23.4 4.13 21.8 3.87
18.0 16.8 28.9 4.81 27.1 4.53 25.2 4.20 24.2 4.08 23.4 3.95 21.8 3.69
20.0 18.5 28.9 4.59 27.1 4.33 25.2 4.04 24.2 3.93 23.4 3.79 21.8 3.53
24.0 20.5 28.9 4.37 27.1 4.15 25.2 3.76 24.2 3.80 23.4 3.64 21.8 3.38
GMV-504WM/G-X
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor air
temp
Indoor air temperature ℃ DB
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
℃ DB ℃ WB kW kW kW kW kW kW kW kW kW kW kW kW
135%
-19.8 -20.0 46.6 12.01 45.5 12.61 44.6 13.05 44.1 13.35 43.8 13.74 42.9 14.31
-18.8 -19.0 47.0 12.21 46.0 12.81 45.0 13.15 44.6 13.51 44.2 13.81 43.3 14.43
-16.7 -17.0 47.8 12.50 46.8 13.07 45.9 13.43 45.4 13.64 45.1 14.00 44.2 14.57
-13.7 -15.0 48.7 12.79 47.6 13.29 46.8 13.62 46.3 13.86 46.0 14.22 45.1 14.68
-11.8 -13.0 49.4 13.03 48.4 13.46 47.6 13.73 47.1 14.03 46.8 14.29 46.0 14.79
-9.8 -11.0 50.3 13.23 49.3 13.65 48.5 13.89 48.0 14.10 47.7 14.34 46.9 14.81
-9.5 -10.0 50.7 13.29 49.7 13.69 48.9 13.89 48.4 14.10 48.1 14.37 47.3 14.76
-8.5 -9.1 51.1 13.37 50.2 13.76 49.3 13.88 48.9 14.15 48.6 14.36 47.8 14.80
-7.0 -7.6 51.7 13.44 50.9 13.77 50.0 13.93 49.5 14.11 49.2 14.35 48.4 14.76
-5.0 -5.6 56.2 14.39 55.3 14.47 54.6 14.94 54.2 15.15 53.8 15.39 53.2 15.76
-3.0 -3.7 56.9 14.38 56.1 14.73 55.4 14.82 55.0 15.07 54.7 15.25 54.0 15.63
0.0 -0.7 58.3 14.32 57.4 14.55 56.7 14.63 56.4 14.81 56.1 15.03 56.1 15.48
3.0 2.2 69.0 16.35 68.4 16.69 67.7 16.82 67.5 17.02 67.3 17.23 63.4 16.74
5.0 4.1 85.0 19.66 79.3 18.87 73.8 17.76 71.0 17.38 68.2 16.95 63.4 16.21
7.0 6.0 85.1 19.17 79.4 18.35 73.9 17.27 71.0 15.06 68.3 16.43 64.1 15.49
9.0 7.9 85.1 18.64 79.5 17.83 73.9 16.74 71.1 16.35 68.8 15.86 64.1 14.56
11.0 9.8 85.1 18.09 79.5 17.27 73.9 16.17 71.1 15.50 68.8 14.91 64.1 13.71
13.0 11.8 85.1 17.50 79.5 16.69 73.9 15.16 71.1 14.53 68.8 14.00 64.1 12.87
15.0 13.7 85.1 16.98 79.5 15.74 73.9 14.29 71.1 13.71 68.8 13.19 64.1 12.15
18.0 16.8 85.1 16.08 79.5 14.98 73.9 13.56 71.1 13.02 68.8 12.47 64.1 11.54
20.0 18.5 85.1 15.31 79.5 14.31 73.9 12.94 71.1 12.44 68.8 11.85 64.1 11.03
24.0 20.5 85.1 14.64 79.5 13.76 73.9 12.45 71.1 11.96 68.8 11.32 64.1 10.63
Combination
Outdoor air
temp
Indoor air temperature ℃ DB
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
℃ DB ℃ WB kW kW kW kW kW kW kW kW kW kW kW kW
GMV6 DC Inverter VRF Units Technical Sales Guide
83
