GMV-680WM/G-X
TC—Total capacity of outdoor unit; PI—Power input of outdoor unit
Combination
Outdoor air
temp
Indoor air temperature ℃ DB
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
℃ DB ℃ WB kW kW kW kW kW kW kW kW kW kW kW kW
135%
-19.8 -20.0 48.7 15.98 48.6 17.13 48.5 18.00 48.4 18.59 48.3 19.26 48.2 20.41
-18.8 -19.0 49.2 16.24 49.1 17.39 48.9 18.13 48.7 18.74 48.6 19.29 48.6 20.54
-16.7 -17.0 50.1 16.66 49.9 17.71 49.7 18.48 49.5 18.88 49.5 19.53 49.3 20.67
-13.7 -15.0 51.0 17.03 50.9 18.04 50.7 18.73 50.5 19.19 50.4 19.80 50.3 20.80
-11.8 -13.0 51.7 17.35 51.6 18.24 51.5 18.84 51.4 19.42 51.3 19.92 51.1 20.90
-9.8 -11.0 54.6 18.26 54.4 19.16 54.1 19.67 53.8 20.06 53.5 20.44 53.1 21.30
-9.5 -10.0 55.9 18.63 55.5 19.42 55.1 19.88 54.8 20.26 54.6 20.74 54.4 21.56
-8.5 -9.1 57.3 19.06 56.6 19.71 56.2 20.09 55.8 20.49 55.6 20.89 55.4 21.79
-7.0 -7.6 58.2 19.23 58.0 19.98 57.8 20.45 57.8 20.90 57.6 21.35 57.4 22.23
-5.0 -5.6 62.2 20.28 61.8 20.56 61.2 21.27 61.0 21.64 60.7 22.03 60.5 22.78
-3.0 -3.7 64.9 20.86 64.2 21.44 64.0 21.74 63.8 22.19 63.6 22.53 63.4 23.31
0.0
-0.7 69.9 21.84 68.9 22.21 68.8 22.54 68.8 22.93 68.5 23.32 68.5 24.03
3.0 2.2 76.2 22.96 75.8 23.53 74.4 23.47 74.1 23.72 74.1 24.11 73.9 24.78
5.0 4.1 79.1 23.27 78.8 23.84 78.4 23.96 78.1 24.30 77.9 24.60 77.6 25.21
7.0 6.0 83.0 23.79 82.8 24.33 82.3 24.43 81.9 22.06 81.9 25.04 79.2 24.31
9.0 7.9 87.0 24.22 86.7 24.73 86.4 24.84 86.2 25.18 84.5 24.75 79.2 22.85
11.0 9.8 91.0 24.59 90.8 25.08 90.5 25.13 87.5 24.23 84.6 23.29 79.2 21.53
13.0 11.8 95.8 25.04 95.6 25.53 90.8 23.65 87.5 22.71 84.6 21.87 79.2 20.20
15.0 13.7 100.4 25.47 96.5 24.29 90.8 22.29 87.5 21.43 84.6 20.61 79.2 19.07
18.0 16.8 100.4 25.40 96.5 24.22 90.8 22.23 87.5 21.37 84.6 20.56 79.2 19.02
20.0 18.5 100.4 25.30 96.5 24.13 90.8 22.15 87.5 21.30 84.6 20.48 79.2 18.95
24.0 20.5 100.4 25.18 96.5 24.02 90.8 22.05 87.5 21.20 84.6 20.39 79.2 18.86
120%
-19.8 -20.0 48.6 17.55 48.5 18.63 48.4 19.36 48.2 19.84 48.1 20.41 48.0 21.61
-18.8 -19.0 49.1 17.77 49.0 18.84 48.8 19.25 48.6 20.01 48.5 20.55 48.4 21.72
-16.7 -17.0 49.9 18.08 49.8 19.10 49.6 19.62 49.4 20.18 49.4 20.74 49.2 21.75
-13.7 -15.0 50.8 18.36
50.7 19.29 50.5 19.86 50.3 20.31 50.3 20.84 50.2 21.86
-11.8 -13.0 51.5 18.60 51.5 19.43 51.3 19.94 51.2 20.38 51.2 20.94 51.1 21.81
-9.8 -11.0 54.5 19.48 54.3 20.30 53.9 20.60 53.8 21.13 53.5 21.46 53.0 22.26
-9.5 -10.0 55.7 19.80 55.3 20.52 54.9 20.86 54.6 21.22 54.3 21.39 54.3 22.49
-8.5 -9.1 56.9 20.13 56.4 20.79 56.1 21.08 55.7 21.46 55.5 21.86 55.3 22.69
-7.0 -7.6 58.1 20.35 57.9 21.02 57.6 21.36 57.6 21.79 57.5 22.27 57.3 22.99
-5.0 -5.6 62.1 21.34 61.7 21.97 61.2 22.22 61.0 22.57 60.7 22.88 60.4 23.60
-3.0 -3.7 64.2 21.69 63.9 22.25 63.5 22.48 63.4 22.84 63.3 23.30 63.2 23.98
0.0 -0.7 69.8 22.78 68.8 23.08 68.5 23.56 68.5 23.67 68.4 24.08 68.3 24.73
3.0 2.2 75.9 23.79 75.5 24.31 74.3 24.14 74.1 24.51 73.9 24.78 73.2 25.01
5.0 4.1 78.9 24.07 78.6 24.58 78.3 24.68 78.1 25.03 77.9 25.31 73.0 23.44
7.0 6.0 82.8 24.53 82.2 24.86 82.1 25.07 81.5 25.01 77.7 23.71 72.6 21.94
9.0 7.9 86.8 24.96 86.3 25.36 83.8 24.32 81.8 23.60 77.7 22.30 72.6 20.65
11.0 9.8 90.8 25.28 88.5 24.81 84.9 23.17 82.0 22.28 77.7 21.00 72.6 19.47
13.0 11.8 94.0 25.01 88.5 23.27 84.9 21.74
82.0 20.93 77.7 19.75 72.6 18.31
15.0 13.7 94.0 23.54 88.5 21.92 84.9 20.53 82.0 19.74 77.7 18.63 72.6 17.29
18.0 16.8 94.0 23.48 88.5 21.86 84.9 20.48 82.0 19.69 77.7 18.59 72.6 17.25
20.0 18.5 94.0 23.39 88.5 21.78 84.9 20.40 82.0 19.62 77.7 18.52 72.6 17.19
24.0 20.5 94.0 23.28 88.5 21.67 84.9 20.31 82.0 19.53 77.7 18.44 72.6 17.11
GMV6 DC Inverter VRF Units Technical Sales Guide
97
