POMPE PER VUOTO LUBRIFICATE PBO – PBOM
OIL LUBRICATED VACUUM PUMPS PBO - PBOM
ED. 4
REV.0
05.2009
COD.564000100
27 di 31
60 PBO-PBOM
(mm)
A
600
B
285
C
395
D
210
E
150
F
122
G
165
H
220
K
215
L
120
M
365
N
114
O
100
P
122
R
50
S
30
Øa
1“ G
Øm
1“ G
Øf
9
X
209
Y
317
W
30
100 PBO-PBOM
(mm)
A
705
B
360
C
440
D
275
E
117
F
118
G
230
H
340
K
258
L
160
M
445
N
115
O
120
P
160
R
61
S
30
Øa
1”1/4G
Øm
1”1/4G
Øf
10
X
231
Y
472
W
30
