2.0.00 SOLLEVAMENTO E TRASPORTO
2.0.01 Sollevamento e trasporto
Il sollevamento delle pompe PBO-PBOM avviene tramite
apposite fasce bilanciandone opportunamente il carico. Le
pompe PBO-PBOM 3 -6 e 12 PBO-M e possono essere
sollevate a mano con la cura di afferrarle saldamente nei
punti indicati.
2.0.00 LIFTING AND TRANSPORT
2.0.01 Lifting and transport
PBO and PBOM vacuum pumps can be lifted by means of
bands to balance their weights.
PBO-PBOM 3 - 6 and 12 can be lifted by hand, picking
them up in the correct positions.
PBO - PBOM 3 – Kg/Kgs. 7
PBO - PBOM 6 – Kg/Kgs. 13
PBO – PBOM 12 – Kg/Kgs. 15.5
PBO-PBOM 28 – Kg/Kgs. 26
PBO-PBOM 40 – Kg/kgs. 49
PBO-PBOM 60 – Kg/Kgs. 64
PBO-PBOM 100 – Kg/Kgs. 87
PBO-PBOM 220 – Kg/Kgs. 150
PBO-PBOM 340 – Kg/Kgs. 190
