BHM-Tech contact mini - Hearing System Components

21
User Instruction
1
Bone conduction receiver
2
Battery compartment
3
Battery size 13
4
Child lock
5
Microphone port
6
Volume control
7
Programming socket –
below socket cover
8
Safety cap
6
3
2
1
Hearing system
components
5
4
7
8
Technical Data according to DIN IEC 118-9
max. acoust.-mech. Sensitivity (dB) 51
max. Output-Force Level (dBOFL) 114
current consumption (mA) 1.06 +-10%
@1.35V
battery size 13
battery life (@ 290mAh battery
capacity)
approx. 270h
