BHO DZF-6050 - Menu I & Menu II

8
*MENU I & MENU II
Under running mode, press and hold “Set” button for 6 seconds; Controller will display “Lc”.
Enter 3 and press “Set” for the menu in MENU I
Enter 9 and press “Set” for menu in MENU II.
After you done with the setting change, press and hold “Set” for 3 seconds to save and exit to running mode.
MENU I:
Prompt Name Description
When Lc = 3, controller enters into the menu below
If SV>(SP+AL), ALM light comes up, buzzer sounds and oven stops heating
Represents the specific control method of the relay.
Pass Key
Over-temp alarm
Control Cycle
Lc
AL
T
P Proportional Increase P reduce temperature overshooting,decrease P to allow faster heating rate.
default Value
3
0~100(5)
5
35
I Integral
Increase I to lower temperature fluctuation
Adjusted to reduce temperature overshooting.
1~1000s
(200s)
D Differential
0~1000s
(200s)
Pb -10~10
(0)
Ambient
adjustment
PK
Et
Hot adjustment
Timing Function
-999~999
(0)
0~2(2)
Offset the temperature difference ambient and oven when it is turn off.
Pb = temperature measured by exterior thermocouple(s) – temperature displayed by
controller
Offset the temperature difference between the controller and actual reading inside
the oven. (use the calibration formula in 5-2 section)
0: no timer function
1: with timer function, SV window will always display dwelling time.
2: with timer function, SV window will display dwelling time after oven temperature
reaches target temperature.
